Upper Gear Unit

1 2 3 4 5 6 7 8 8 8 8 8 9 10 11 12 13 13 14 15 16 17 18 19 20 21 22 23 24 25 26 26 26 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 40 40 41 41 41 41 41 42 42 42 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 80 80 80 80 80 80 80 80 81 82 83 84 85 86 87 88 89 90 90 |$22 |$42 |$42 |$83

#	Наименование	Код
1	Gear housing	3854378
2	Gear housing	3854384
3	Insert	3852541
4	Insert	3852567
5	Insert	3852515
6	Insert	3852513
7	Ring, thrust plate	3852516
8	Shim, upper bearing, 0.004 in	3852365
8	Shim, upper bearing, 0.003 in	3852364
8	Shim, upper bearing, 0.002 in	3852363
8	Shim, upper bearing, 0.005 in	3852366
8	Shim, upper bearing, 0.010 in	3852367
9	Screw, top cover	3850629
10	Gasket, top cover	3852317
11	O-ring, oil fill plug	3852045
12	Turn signal, oil indicator	3852297
13	Kit	21130692
13	Drive gear set, pinion & drive gears	3852396
14	Gear	0004009532
15	Pinion	0004009533
16	Bearing housing, pinion	3852267
17	Ring, upper bearing support	3852269
18	Universal joint	3852384
19	Yoke	3850815
20	Spacer	3850813
21	Yoke	3850814
22	Spider	3850812
23	Locking clip, u-joint	3850757
24	Washer, pinion gear	3852310
25	Sealing, u joint to bearing carrier	3852272
26	Adjusting washer, bearing carrier, 0.005 in	3852357
26	Adjusting washer, bearing carrier, 0.010 in	3852358
26	Shim, bearing carrier, 0.003 in	3852355
26	Adjusting washer, bearing carrier, 0.004 in	3852356
27	O-ring, bearing carrier	3852308
28	Flange screw, bearing carrier	3852454
29	O-ring, u joint	3852565
30	Bearing, drive gear	3852390
31	Gasket, water passage	3852279
32	Locking clip, upper driveshaft	3852295
33	Snap ring, spring	3852299
34	Sleeve, pretension	3852304
35	Sliding sleeve	3852293
36	Shaft, upper	3852292
37	Ring, bearing retainer	3852262
38	Screw, water passage	3852373
39	Bearing, drive gear	3852389
40	Shim, lower bearing, 0.002 in	3852368
40	Shim, lower bearing, 0.005 in	3852371
40	Shim, lower bearing, 0.003 in	3852369
41	Shim, upper cover, 0.010 in	3852372
41	Shim, upper cover, 0.005 in	3852371
41	Shim, u er cover, 0.004 in	3852370
41	Shim, upper cover, 0.003 in	3852369
41	Shim, upper cover, 0.002 in	3852368
42	Nut, upper driveshaft, 0.000 in	3852301
42	Nut, upper driveshaft, 0.008 in	3852302
42	Nut, upper driveshaft, 0.016 in	3852303
42	Nut, upper driveshaft, 0.024 in	3852375
43	Spacer, spring	3852298
44	Lock ring, seal	3852307
45	Screw, pinion gear retainer	3852309
46	Bearing, pinion to inner carrier	3850852
47	Bearing, pinion to outer carrier	3850853
48	Spring, clutch cone to shaft	3852296
49	Plug, oil plug	3854539
50	O-ring, oil plug	3855081
51	Adjusting washer, thrust plate, 0.015 in	3852563
52	Pressure plate, thrust, port	3852561
53	Pressure plate, thrust, starboard	3852562
54	Bearing cover, upper gear unit	3854401
55	Insert, threaded, 5/16-18	3852513
56	Strainer, oil sump	3854021
57	Shift mechanism	3852410
58	Dog	839646
59	Spring, shift shoe	814184
60	O-ring, shift actuator	925093
61	Bearing housing	839505
62	Sealing ring	853868
63	Spring pin	951924
64	Clevis pin	942871
65	Eccentric piston	897816
66	Shim, shift shoe	897871
67	Hexagon screw, shift shoe stop	897711
68	Bracket, shift	3852276
69	Cube, cable to bellcrank	3852329
70	Fork, shift link	3852328
71	Link, bellcrank to piston	3852278
72	Split pin	3854480
73	Bar, bellcrank	3852277
74	Clevis pin, shift link to piston	3852330
75	Screw, shift housing	3852353
76	Washer, shift	3852184
77	Washer, bellcrank	3852193
78	Washer, shift link	3852083
79	Plate, waterpassage	3852280
80	Decal	3851030
80	Decal	3851029
80	Decal	3851028
80	Decal	3851027
80	Decal	3851026
80	Decal	3851025
80	Decal	3851024
80	Decal	3851023
80	Decal	3851031
81	Cover, shift mechanism	3852418
82	Flange screw, cover	3852568
83	Ring, Spacer	3852294
84	Split pin, shift cable	3854480
85	Grommet	3853424
86	Nut, drive to pivot housing	3853329
87	Bushing	3853423
88	Kit	3850594
89	Sealing, water passage	3852560
90	Decal	3850634
90	Decal	3850635
\|$22	Bulletin P-44-1-5	0004009537
\|$42	Bulletin P-44-1-18	0004009559
\|$42	Bulletin P-44-1-8	0004009558
\|$83	Bulletin P-44-1-7	0004009601
