Lower Gear Unit

1 1 1 1 1 2 3 4 5 6 6 6 6 7 8 9 10 11 12 13 13 13 13 13 14 14 14 14 14 14 14 14 14 14 14 14 14 14 14 15 16 17 18 18 18 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 49 50 50 51 52 53 54 55 56 |$100 |$101 |$106 |$77 |$78 |$79 |$80 |$81 |$82 |$83 |$84 |$88 |$89 |$90 |$91 |$98 |$99

#	Наименование	Код
1	Gear housing	3854379
1	Gear housing	3854385
1	Gear housing	3854382
1	Gear housing	3854381
1	Gear housing	3854380
2	Insert	3852513
3	Insert	3852567
4	Bearing, pinion	3853934
5	Insert, prop shaft retainer	3852515
6	Drive gear set	3852403
6	Drive gear set	3852405
6	Drive gear set	3852402
6	Drive gear set	3852404
7	Rotor	3853941
8	Bearing, gear to gearcase	3850942
9	Nut, pinion to driveshaft	3851003
10	Roller bearing, prop shaft housing	3854249
11	Seal, prop shaft housing	3853474
12	O-ring, propeller shaft hsg	3852865
13	Shim, gear position, 0.002 in	3850695
13	Shim, gear position, 0.004 in	3852885
13	Shim, gear position, 0.003 in	3852886
13	Shim, gear position, 0.005 in	3852887
13	Shim, gear position, 0.010 in	3852888
14	Ring, shim, prop shaft hsg., 0.120''	3852878
14	Ring, shim, prop shaft hsg., 0.124''	3852880
14	Ring, shim, prop shaft hsg., 0.122''	3852879
14	Ring, shim, prop shaft hsg., 0.114''	3852875
14	Ring, shim, prop shaft hsg., 0.118''	3852877
14	Ring, shim, prop shaft hsg., 0.116''	3852876
14	Ring, shim, prop shaft hsg., 0.112''	3852874
14	Ring, shim, prop shaft hsg., 0.108''	3852872
14	Ring, shim, prop shaft hsg., 0.100''	3852868
14	Ring, shim, prop shaft hsg, 0.096''	3852881
14	Ring, shim, prop shaft hsg., 0.106''	3852871
14	Ring, shim, prop shaft hsg., 0.110''	3852873
14	Ring, shim, prop shaft hsg., 0.102''	3852869
14	Ring, shim, prop shaft hsg., 0.098''	3852882
14	Ring, shim, prop shaft hsg., 0.104''	3852870
15	Countershaft, lower	3852337
16	Roller bearing, driveshaftl lower	3854249
17	Roller bearing, driveshaftl upper	3854250
18	Shim, pinion position, 0.003 in	3852889
18	Shim, pinion position, 0.004 in	3852890
18	Shim, pinion position, 0.005 in	3852891
18	Shim, pinion position, 0.010 in	3852892
19	Housing, propeller shaft	3853492
20	Screw, prop shaft housing	3853272
21	Propeller shaft	3852271
22	Flange screw, guide & seal	3852454
23	O-ring, support housing	3852866
24	O-ring, oil passage	3852959
25	Plug, gearcase plug	3854539
26	O-ring, gearcase plug (a)	3855081
27	Anode, prop shaft housing	3852970
28	Retainer, anode	3852971
29	Screw, anode	3852972
30	Screw, anode retainer	3853309
31	Washer, anode	3852973
32	Retainer, driveshaft	3852883
33	Retainer, prop shaft housing	3853371
34	Screw, prop shaft retainer	3852478
35	Guide, water tube (a)	3853932
36	Plug, trim tab hole	3850662
37	Screw, trim tab	3852008
38	Trim fin	3854402
39	Screw, lower to upper housing	3852349
40	Screw, lower to upper housing	3853262
41	Screw, lower to upper housing	3852960
42	Splined sleeve, intermediate	3852268
43	Split pin, propeller	3852056
44	Spacer, propeller nut	3852350
45	Bushing	3852020
46	Propeller nut, propeller	3850984
47	Tube, water supply	3852314
48	Sealing, water supply tube	3852315
49	Propeller, 15 x 17	0004009714
49	Propeller, 14 ?? x 21	3850302
49	Propeller, 14 ?? x 19	3850308
49	Propeller, 15 x 17	3850307
49	Propeller, 15 x 16	3850306
49	Propeller, 15 ?? x 14	3850304
49	Propeller, 15 ?? x 15	3850299
49	Propeller, 14 ?? x 19	3850301
49	Propeller, 15 x 17	3850300
49	Propeller, 14 ?? x 23	3850310
49	Propeller, 15 ?? x 13	3850298
49	Propeller, 15 x 15	0004009731
49	Propeller, 15 x 17	0004009722
49	Propeller, 14 ?? x 23	0004009720
49	Propeller, 14 ?? x 21	3850309
49	Propeller, 14 ?? x 23	3850303
49	Propeller, 15 x 17	3850311
49	Propeller, 14 ?? x 19	3850312
49	Propeller, 14 ?? x 21	3850313
49	Propeller, 14 ?? x 23	3850314
49	Propeller, 15 x 15	3850315
49	Propeller, 14 ?? x 19	3850317
49	Propeller, 14 ?? x 21	3850318
49	Propeller, 14 ?? x 19	3850321
49	Propeller, 14 ?? x 21	3850322
49	Propeller, 14 ?? x 23	3850323
50	Bushing, propeller	3850324
50	Bushing, propeller	3850325
51	Sleeve, bushing	3850831
52	Ring, converging	3854241
53	Zinc anode	3853818
54	Washer, anode	3852182
55	Hexagon screw, anode	3852186
56	Kit	3850597
\|$100	Bulletin 56-11	0004009752
\|$101	Bulletin 56-11	0004009754
\|$106	Bulletin P-44-1-1	0004009760
\|$77	Bulletin 56-11	0004009715
\|$78	Bulletin 56-11	0004009717
\|$79	Bulletin 56-11	0004009719
\|$80	Bulletin 56-11	0004009721
\|$81	Bulletin 56-11	0004009723
\|$82	Bulletin 56-11	0004009725
\|$83	Bulletin 56-11	0004009727
\|$84	Bulletin 56-11	0004009729
\|$88	Bulletin 56-11	0004009734
\|$89	Bulletin 56-11	0004009736
\|$90	Bulletin 56-11	0004009738
\|$91	Bulletin 56-11	0004009740
\|$98	Bulletin 56-11	0004009748
\|$99	Bulletin 56-11	0004009750
