Купить Приводы и трансмиссии SX-C SX-C1 SX-C2 SX-CT SX-CT1 SX-R SX-RT1 SX-RT2 DP-S DP-S1 SX-C1AC TSK SX-C1 TSK SX-C1AC TSK DP-S TSK SX-C SX-CT Transmissions Transom Shield для лодочных моторов Volvo Penta в Москве

Transom Shield

1 2 3 4 5 5 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 40 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 58 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 74 74 74 74 74 75 76 77 78 79 80 81 82 83 83 83 84 85 86 87 88 88 89 90 91 92 93 94 95 |$101 |$25 |$58 |$6

#	Наименование	Код
1	Nut, steering arm stud	3852004
2	Grommet, pivot pin	3853424
3	Screw, shift cable retainer	3852006
4	Washer, anode	3852061
5	Bellows, u joint	0004007680
5	Bellows kit	22197130
5	Bellows kit	3841481
6	Hexagon screw, support hsg to gimbal hsg	3852151
7	Hose clamp, water hose	3852602
8	Washer, gimbal to gimbal hsg	3852557
9	Washer, trim sender to gimbal	3853458
10	Washer, anode	3852191
11	Hexagon screw, clamp, oil line assy, gimbal hsg	3852201
12	Pin connector, sending unit (3 pin)	3852239
13	Nipple, water inlet	3852533
14	Nut, nipple, water intet	3852534
15	O-ring, Nipple	3852535
16	Retainer, shift cable	3852313
17	Retainer, bellows to pivot hsg, exhaust	3852665
18	Shaft, steering pivot	3855960
19	Washer, screw, clamp, oil assy, gimbal hsg	3852191
20	Screw, gimbal to pivot	3852316
21	Washer, steering arm	3852554
22	Cardboard tube	3854246
23	Bracket	3852380
24	Bellows	3850426
25	Screw, steering arm to gimbal	3852591
26	Arm	3852379
27	Chassis ground cable, pivot housing to gimbal	3853929
28	Hose, water intet	3852352
29	Cable tie, water intet to hose	948616
30	Screw, cover steering arm	3852682
31	O-ring, sleeve & connector assy to gimbal hsg	3852537
32	Cover, gimbal hsg	3855005
33	Clamp, dit line assy, gimbal hsg	3852354
34	Flange screw, cap to gimbal hsg	3852473
35	Hose clamp, exhaust bellows	3852603
36	Hose clamp, u joint bellows	3852604
37	Suspension fork	3854863
38	Stud, gearcase to upper gear hsg	941814
39	Plate, steering arm mounting	3852585
40	Housing	3851976
40	Washer	3852193
40	Plug, hole, accessory access	3851975
41	Thread insert, exhaust pipe	3852953
42	Insert, threaded, 318-16	3852515
43	Insert, threaded, 5116-18	3852513
44	Insert, steering cover	3852567
45	Nut, stud, manifold block	3852005
46	Fitting, tube, u joint bearing	3852121
47	Stud, manifold block	3852141
48	O-ring	3852169
49	Stud, transom, long	3852546
50	Bearing, upper steering	3852547
51	Sealing, drive shaft	3852548
52	Pin, support housing	3852549
53	Sealing, transom	3852550
54	Block	3852559
55	Sealing	0004007736
56	Tube, grease fitting	3852564
57	Stud, transom, short	3852576
58	Bearing	21752712
58	Ball bearing	3855707
58	Bearing	3853807
59	Insert	3852526
60	Flange screw, retainer, water tube	3852454
61	Bushing, water tube	3852556
62	Pipe, gimbal hsg	3853880
63	Retainer, plug to gimbal hsg	3852555
64	Washer, stud, manifold block	3852193
65	Cable sleeve	3850694
66	Washer	3855350
67	O-ring	3852523
68	Plug	3852536
69	Washer, gimbal to pivot hsg	3852697
70	Washer, pivot screw, pivot hsg	3852558
71	Stud, pivot to gear hsg	3852551
72	Insert	3852514
73	Washer, steering support brkt to gimbal hsg	3852155
74	Sensor	3849411
74	Sensor	3861837
74	Sensor	3594989
74	Wire	3863007
74	Bracket	3855535
74	Sensor	3854842
75	Terminal, socket	3852257
76	Cable tie, trim sender lead to grease tube	0004007765
77	Sealing kit	3854270
78	Bushing, pivot pin, trim & tilt cylinder	3853423
79	Gasket, cap, gimbal hsg	3852677
80	Washer, gimbal to support bracket	3852557
81	Sealing, water passage	3852560
82	Bearing, steering & tilt	3852544
83	Spacer, anode	3851823
83	Hexagon screw, anode	940172
83	Hexagon screw, anode	3852192
84	Washer, ground strap	3852193
85	Dowel, steering arm	3852545
86	Sleeve, gimbal	3852571
87	Screw	3852081
88	Anode	3854130
88	Magnesium anode	3855610
89	Screw	3852050
90	Protection against c	3851984
91	Sensor	3851985
92	Wiring harness	3855793
93	Electronic unit	3851972
94	Hexagon screw	3855728
95	O-ring	3852044
\|$101	Bulletin P-44-1-1	0004007781
\|$25	Bulletin P-44-1-20	0004007703
\|$58	Bulletin P-25-2-2	0004007737
\|$6	Bulletin P-44-1-27	0004007683
