Upper Gear Unit Sail Boat Drive Unit 130S 130SR Components

1 2 3 4 5 6 7 8 9 10 11 11 11 11 11 12 13 13 13 13 13 13 14 15 16 17 18 19 20 21 22 22 22 22 22 22 22 23 24 25 26 27 28 29 30 31 32 33 33 33 33 33 34 35 36 37 38 39 39 39 39 39 40 41 41 41 41 41 41 41 41 42 43 44 45

#	Наименование	Код
1	Input shaft	0003991654
2	Input shaft	3841088
3	Key	3582591
4	Roller bearing	183834
5	Thrust washer	3582571
6	Inner race	3582904
7	Needle bearing	3582905
8	Spacer ring	3582906
9	Spacer	3582914
10	Bushing	3582907
11	Shim	3582908
11	Shim	3582911
11	Shim	3586721
11	Shim	3586723
11	Shim	3582910
12	Gear set	3586547
13	Shim	3586728
13	Shim	948300
13	Shim	3582568
13	Shim	948298
13	Shim	3586724
13	Shim	948299
14	Spacer	3582914
15	Ring	3582913
16	Disc spring	3808598
17	End disc	3849908
18	Lock ring	3582917
19	Disc kit	3848817
20	Disc, outer	3582579
21	Disc, inner	3582578
22	Shim	3582581
22	Shim	3583429
22	Shim	3583430
22	Shim	3582580
22	Shim	3582583
22	Shim	3582582
22	Shim	3582872
23	Gear selector contro	3593848
24	Torsion spring	3582024
25	Retainer	0003991693
26	Ring	3582898
27	Ball	3582585
28	Spindle	3582590
29	Spring	3582588
30	Stop pin	3582589
31	Sleeve	0003991699
32	Retainer	0003991700
33	Shim	3586727
33	Shim	3586726
33	Shim	3586725
33	Shim	3582900
33	Shim	3582901
34	Washer	3582899
35	Screw	3808717
36	Gear	3582879
37	Roller bearing	11041
38	Roller bearing	183834
39	Shim	3586729
39	Shim	3586731
39	Shim	3586730
39	Shim	3582874
39	Shim	3582875
40	Spacer	3582880
41	Shim	3583430
41	Shim	3583429
41	Shim	3582872
41	Shim	3808718
41	Shim	3582583
41	Shim	3582582
41	Shim	3582581
41	Shim	3582580
42	Lock nut	3582925
43	Hexagon screw	955271
44	Splined sleeve	3582894
45	Lock ring	3583350
