Upper Gear Unit Sail Boat Drive Unit MS25S MS25SR Components: RATIO 2.47:1

1 2 3 4 5 6 7 8 9 10 11 11 11 11 12 13 13 13 13 14 15 16 16 17 18 19 20 20 20 20 20 20 20 21 22 23 24 25 26 27 28 29 30 30 30 30 31 32 33 34 35 35 35 36 37 37 37 37 37 37 37 38 39 40 41 42

#	Наименование	Код
1	Upper gear	3583351
2	Input shaft	3841088
3	Key	3582591
4	Roller bearing	183834
5	Thrust washer	3582571
6	Inner race	3582904
7	Needle bearing	3582905
8	Spacer ring	3582906
9	Ring	3583327
10	Bushing	3582907
11	Shim	3582911
11	Shim	3582910
11	Shim	3582908
11	Shim	3586723
12	Gear set	3583328
13	Shim	948299
13	Shim	948298
13	Shim	948300
13	Shim	3582568
14	Spacer	3582914
15	Lock ring	3582913
16	Spring	3582915
16	Disc spring	3808598
17	End disc	3582916
18	Lock ring	3582917
19	Disc kit	877370
20	Shim	3582580
20	Shim	3583429
20	Shim	3582582
20	Shim	3582872
20	Shim	3582583
20	Shim	3582581
20	Shim	3583430
21	Torsion spring	3582024
22	Retainer	3583344
23	Ring	3582898
24	Ball	3582585
25	Spindle	3582590
26	Spring	3582588
27	Stop pin	3582589
28	Sleeve	3583345
29	Retainer	3583343
30	Shim	3583346
30	Shim	3582900
30	Shim	3586727
30	Shim	3582901
31	Washer	3582899
32	Hexagon screw	970948
33	Gear	3582879
34	Roller bearing	11041
35	Shim	3582873
35	Shim	3582875
35	Shim	3582874
36	Spacer	3582880
37	Shim	3583430
37	Shim	3583429
37	Shim	3582872
37	Shim	3582583
37	Shim	3582582
37	Shim	3582581
37	Shim	3582580
38	Roller bearing	183834
39	Lock nut	3582925
40	Hexagon screw	955271
41	Splined sleeve	3582894
42	Lock ring	3583350
