| # | Наименование | Код | |
| 1 | Heat exchanger | 3826339 | |
| 2 | Housing | 3826787 | |
| 3 | End plate | 3826789 | |
| 4 | O-ring | 3826783 | |
| 5 | Spacer | 3826782 | |
| 6 | Insert | 3826790 | |
| 7 | End plate | 3826788 | |
| 8 | Hex. socket screw | 959224 | |
| 9 | Hose connection | 866592 | |
| 10 | O-ring | 125362 | |
| 11 | Hex. socket screw | 959222 | |
| 12 | Gasket | 907132 | |
| 13 | Plug | 960628 | |
| 14 | Pressure cap | 866761 | |
| 15 | Anode | 838929 | |
| 16 | Plug | 838928 | |
| 17 | Hose | 192618 | |
| 18 | Washer | 191172 | |
| 19 | Hexagon screw | 980359 | |
| 20 | Shut-off cock | 966871 | |
| 21 | Flange screw | 947760 | |
| 22 | Hose | 3826314 | |
| 23 | Hose | 3830674 | |
| 24 | Hose clamp | 961672 | |
| 25 | Hose clamp | 961673 | |
| 26 | Tube | 866594 | |
| 27 | O-ring | 866690 | |
| 28 | Hose | 3826393 | |
| 29 | Hose clamp | 961671 | |
| 30 | Hose clamp | 961672 | |
| 31 | Elbow nipple | 954385 | |
| 32 | Support sleeve | 944717 | |
| 33 | Sleeve | 954364 | |
| 34 | Fitting nut | 954356 | |
| 35 | Tube | 945460 | |
| 36 | Gasket | 864491 | |
| 37 | Tube | 3826300 | |
| 38 | Bracket | 965577 | |
| 39 | Flange screw | 945444 | |
| 40 | Flange screw | 946544 | |
| 41 | Clamp | 952627 | |
| 42 | Flange nut | 945407 | |
| 43 | Stay | 3826392 | |
| 44 | Flange screw | 965180 | |
| 45 | Decal | 3826722 | |
| 45 | Decal | 3826723 |
