| # | Наименование | Код | |
| 1 | Alternator | 858838 | |
| 1 | Alternator | 872018 | |
| 1 | Alternator | 858838 | |
| 17A | Screw | 859312 | |
| 2 | Rotor | 0003890725 | |
| 2 | Rotor | 0003890649 | |
| 2 | Rotor | 0003890673 | |
| 3 | Stator | 859421 | |
| 3 | Stator | 859421 | |
| 3 | Stator | 859421 | |
| 4 | Mounting kit | 6212688 | |
| 4 | Mounting kit | 6212688 | |
| 4 | Mounting kit | 6212688 | |
| 5 | Fan | 0003890728 | |
| 5 | Fan kit | 860281 | |
| 5 | Fan | 840621 | |
| 6 | End plate | 0003890653 | |
| 6 | End plate | 0003890681 | |
| 6 | End plate | 0003890729 | |
| 7 | Ball bearing | 860432 | |
| 7 | Ball bearing | 860432 | |
| 7 | Ball bearing | 860432 | |
| 8 | Housing | 0003890655 | |
| 8 | End plate | 0003890683 | |
| 8 | End plate | 0003890731 | |
| 9 | Mounting kit | 840625 | |
| 9 | Mounting kit | 840625 | |
| 9 | Mounting kit | 840625 | |
| 10 | Screw kit | 840626 | |
| 10 | Screw kit | 0003890685 | |
| 10 | Screw kit | 840626 | |
| 11 | Diode bridge | 1698689 | |
| 11 | Diode bridge | 1698689 | |
| 11 | Diode bridge | 1698689 | |
| 12 | Bearing race | 840629 | |
| 12 | Bearing race | 840629 | |
| 12 | Bearing race | 840629 | |
| 13 | Ball bearing | 864351 | |
| 13 | Ball bearing | 864351 | |
| 13 | Ball bearing | 864351 | |
| 14 | Protecting casing | 840631 | |
| 14 | Protecting casing | 840631 | |
| 14 | Protecting casing | 840631 | |
| 15 | Regulator kit | 872367 | |
| 15 | Regulator kit | 872367 | |
| 15 | Regulator kit | 872367 | |
| 16 | Screw | 859312 | |
| 16 | Screw | 859312 | |
| 16 | Screw | 859312 | |
| 17 | Brush retainer | 840632 | |
| 17 | Brush retainer | 840632 | |
| 17 | Brush retainer | 840632 | |
| 18 | Flange nut | 965483 | |
| 18 | Hexagon nut | 955779 | |
| 18 | Hexagon nut | 955779 | |
| 18 | Flange nut | 945407 | |
| 18 | Flange nut | 945407 | |
| 18 | Flange nut | 965483 | |
| 18 | Screw | 859312 | |
| 19 | Spring washer | 941904 | |
| 19 | Spring washer | 941904 | |
| 19 | Flange nut | 945407 | |
| 19 | Hexagon nut | 955779 | |
| 19 | Flange nut | 965483 | |
| 20 | Guide | 840634 | |
| 20 | Spring washer | 941904 | |
| 20 | Guide | 840634 | |
| 21 | Guide | 840634 | |
| 5A | Fan | 0003890677 | |
| 5B | Spacer | 862897 | |
| 5C | Spacer | 860284 | |
| 5D | Washer | 860283 |
