| # | Наименование | Код | |
| 1 | Radiator | 3829280 | |
| 2 | Pressure cap | 866095 | |
| 3 | Plug | 960630 | |
| 4 | Gasket | 969011 | |
| 5 | Hose | 192618 | |
| 6 | Gasket | 11994 | |
| 7 | Plug | 947660 | |
| 8 | Fan shroud | 3827773 | |
| 9 | Intercooler | 866090 | |
| 10 | Sealing strip | 3827817 | |
| 11 | Sealing strip | 3827816 | |
| 12 | Flange screw | 946173 | |
| 13 | Flange screw | 967949 | |
| 14 | Rubber cushion | 849170 | |
| 15 | Spring washer | 940280 | |
| 16 | Hexagon nut | 955850 | |
| 17 | Radiator stay | 3835303 | |
| 18 | Hexagon nut | 955793 | |
| 19 | Spring washer | 941912 | |
| 20 | Washer | 948556 | |
| 21 | Rubber bushing | 866857 | |
| 22 | Spacer sleeve | 252202 | |
| 23 | Anchorage | 475888 | |
| 24 | Radiator hose | 865194 | |
| 25 | Hose clamp | 943480 | |
| 26 | Radiator hose | 865195 | |
| 27 | Hose clamp | 994560 | |
| 28 | Rubber hose | 943367 | |
| 29 | Elbow nipple | 942649 | |
| 30 | Radiator protector | 865208 | |
| 31 | Flange screw | 947760 | |
| 32 | Emblem | 846118 | |
| 33 | Cross recessed sunk | 941651 | |
| 34 | Fan hub | 3829422 | |
| 35 | Flange screw | 965222 | |
| 36 | Fan, pusher type | 3828964 | |
| 37 | Fan guard | 3825490 | |
| 38 | Flange screw | 945444 | |
| 39 | Cable tie | 948211 | |
| 40 | Charge air hose | 865127 | |
| 41 | Hose clamp | 865575 | |
| 42 | Charge air pipe | 865137 | |
| 43 | Clamp | 952637 | |
| 44 | Hexagon screw | 945970 | |
| 45 | Hose | 866689 | |
| 46 | Hose clamp | 1544731 | |
| 47 | Charge air pipe | 3831070 | |
| 48 | Plastic plug | 845422 | |
| 49 | Expansion tank | 3827367 | |
| 50 | Elbow nipple | 479953 | |
| 51 | Tensioning band | 339958 | |
| 52 | Hexagon screw | 31406 | |
| 53 | Pin | 31405 | |
| 54 | Clevis pin | 31404 | |
| 55 | Rubber hose | 943367 | |
| 56 | Hose clamp | 994556 | |
| 57 | Rubber hose | 943366 | |
| 58 | Bracket | 3826803 | |
| 59 | Bracket | 3832725 | |
| 60 | Bracket | 3832724 | |
| 61 | Rubber hose | 943367 | |
| 62 | Pressure cap | 1674083 | |
| 63 | Rubber collar | 3828863 | |
| 64 | Flange lock nut | 971098 | |
| 65 | Flange screw | 946329 | |
| 66 | Elbow nipple | 942649 | |
| 67 | Plug | 960632 | |
| 68 | Decal | 3825346 | |
| 69 | Decal | 3827294 | |
| 70 | Coolant pipe | 3835788 | |
| 71 | Flange screw | 965212 |
