| # | Наименование | Код | |
| 1 | Alternator, exch, exch | 3803499 | |
| 1 | Alternator, exch | 3803577 | |
| 1 | Alternator | 849747 | |
| 1 | Alternator | 849748 | |
| 2 | nut | 0003661763 | |
| 2 | End plate | 0003661789 | |
| 3 | Stator | 862506 | |
| 3 | washer | 0003661764 | |
| 4 | Rotor | 862507 | |
| 4 | Fan | 0003661765 | |
| 5 | 0003661766 | ||
| 5 | End plate | 0003661792 | |
| 6 | Rotor | 862528 | |
| 6 | Bearing | 862509 | |
| 7 | Bearing | 862510 | |
| 7 | Stator | 862529 | |
| 8 | Bearing | 862509 | |
| 8 | Slip ring | 862511 | |
| 9 | Seal | 862532 | |
| 9 | nut | 0003661796 | |
| 10 | 0003661771 | ||
| 10 | washer | 0003661797 | |
| 11 | Fan | 0003661798 | |
| 11 | Bearing | 862533 | |
| 12 | Spacer | 0003661799 | |
| 12 | Slip ring | 862511 | |
| 13 | screw | 0003661800 | |
| 13 | screw | 0003661774 | |
| 14 | Sealing | 862520 | |
| 14 | screw | 0003661775 | |
| 15 | Retainer | 862521 | |
| 15 | screw | 0003661776 | |
| 16 | Retainer | 0003661803 | |
| 16 | 0003661777 | ||
| 17 | Diode | 862534 | |
| 17 | woodruff key | 0003661804 | |
| 18 | Rectifier diode | 862535 | |
| 18 | washer | 0003661805 | |
| 19 | screw | 0003661806 | |
| 19 | capacitor | 0003661780 | |
| 20 | insulating plate | 0003661781 | |
| 20 | Diode | 862512 | |
| 21 | screw | 0003661808 | |
| 21 | Brush set | 862536 | |
| 22 | Governor | 862539 | |
| 22 | Rectifier plate | 862513 | |
| 23 | sleeve | 0003661810 | |
| 23 | screw | 0003661784 | |
| 24 | Rectifier plate | 862514 | |
| 24 | screw | 0003661785 | |
| 25 | Kit | 0003661812 | |
| 26 | screw | 0003661813 | |
| 27 | Diode | 862512 | |
| 28 | Seal | 862524 | |
| 29 | Seal | 862524 | |
| 30 | Brush set | 862517 | |
| 31 | Cover | 0003661818 | |
| 32 | insulating plate | 0003661819 | |
| 33 | Governor | 862526 | |
| 34 | screw | 0003661821 |
