| # | Наименование | Код | |
| 1 | Water pump | 860787 | |
| 1 | Water pump | 860785 | |
| 2 | housing | 0003652696 | |
| 2 | housing | 0003652717 | |
| 3 | shaft | 0003652718 | |
| 3 | shaft | 0003652697 | |
| 4 | Wear ring | 421306 | |
| 4 | Wear ring | 421306 | |
| 5 | Sealing ring | 1545283 | |
| 5 | Sealing ring | 1545283 | |
| 6 | Deflector | 70913 | |
| 6 | Deflector | 70913 | |
| 7 | Ball bearing | 1660609 | |
| 7 | Ball bearing | 1660609 | |
| 8 | Ball bearing | 181538 | |
| 8 | Ball bearing | 181538 | |
| 9 | Snap ring | 914462 | |
| 9 | Snap ring | 914462 | |
| 10 | Pulley | 1542235 | |
| 10 | Pulley | 1542235 | |
| 11 | Hub | 860455 | |
| 11 | Hub | 860455 | |
| 12 | Flange screw | 946173 | |
| 12 | Flange screw | 946173 | |
| 13 | Plug | 952077 | |
| 13 | Repair kit | 876560 | |
| 13 | Repair kit | 876561 | |
| 13 | Plug | 952077 | |
| 14 | Flange screw | 947760 | |
| 14 | Flange screw | 947760 | |
| 15 | Gasket | 859027 | |
| 15 | Gasket | 859027 | |
| 16 | O-ring | 968927 | |
| 16 | O-ring | 968927 | |
| 17 | Pipe | 858218 | |
| 17 | Tube | 838738 | |
| 18 | Sealing ring | 1542198 | |
| 18 | Sealing ring | 1542198 | |
| 19 | drive belt | 0003652735 | |
| 19 | drive belt | 0003652714 |
