Crank Mechanism: B

1 1 1 1 1 1 1 1 2 2 2 2 22A 22A 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 12 12 13 13 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 25 26 26 |$1

#	Наименование	Код
1	Piston kit	3583211
1	Piston kit	3583212
1	Piston kit	3583072
1	Piston kit	3583213
1	Piston kit	3583272
1	Piston kit	3583273
1	Piston kit	3583274
1	Piston kit	861045
2	Piston ring kit	859642
2	Piston ring kit	859944
2	Piston ring kit	3581159
2	Piston ring kit	3581158
22A	Washer	861452
22A	Washer	861452
3	Piston	0003925438
3	Piston	0003925506
4	Piston pin	0003925507
4	Piston pin	0003925439
5	Lock ring	859948
5	Lock ring	859948
6	Connecting rod kit	876675
6	Connecting rod kit	876675
7	Bushing	859646
7	Bushing	859646
8	Screw	859644
8	Screw	859644
9	Nut	859645
9	Nut	859645
10	Crankshaft	3581328
10	Crankshaft	3581328
11	Guide pin	859639
11	Guide pin	859639
12	Big-end bearing kit	859807
12	Big-end bearing kit	859949
12	Big-end bearing kit	859949
12	Big-end bearing kit	859807
13	Main bearing kit	859791
13	Main bearing kit	859945
13	Main bearing kit	859791
13	Main bearing kit	859945
14	Thrust washer kit	3580720
14	Thrust washer kit	3580720
15	Flywheel	3580813
15	Flywheel	3580813
16	Ring gear	859720
16	Ring gear	859720
17	Screw	859721
17	Screw	859721
18	Pulley	3581332
18	Pulley	3581332
19	Screw	859762
19	Screw	859762
20	Screw	11997812
20	Screw	11997812
21	Ring	861592
21	Ring	861592
22	Lock	861593
22	Lock	861593
23	Gear pulley	3581331
23	Gear pulley	3581331
24	Key	3581330
24	Key	3581330
25	Vibration damper	3582170
25	Clutch	3581526
25	Vibration damper	854345
26	Shoulder screw	859710
26	Shoulder screw	859710
\|$1	Bulletin 43-10	0003925432
