Crank Mechanism: A

1 1 1 1 1 1 1 1 2 2 2 2 22A 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 12 12 13 13 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26

#	Наименование	Код
1	Piston kit	3583275
1	Piston kit	3583276
1	Piston kit	3583278
1	Piston kit	3583279
1	Piston kit	3583280
1	Piston kit	3583281
1	Piston kit	3583282
1	Piston kit	3580775
2	Piston ring kit	859642
2	Piston ring kit	859642
2	Piston ring kit	859944
2	Piston ring kit	859944
22A	Washer	861452
3	Piston	0003925472
3	Piston	0003925404
4	Piston pin	0003925405
4	Piston pin	0003925473
5	Lock ring	859948
5	Lock ring	859948
6	Connecting rod kit	876675
6	Connecting rod kit	876675
7	Bushing	859646
7	Bushing	859646
8	Screw	859644
8	Screw	859644
9	Nut	859645
9	Nut	859645
10	Crankshaft	3581328
10	Crankshaft	3581328
11	Guide pin	859639
11	Guide pin	859639
12	Big-end bearing kit	859949
12	Big-end bearing kit	859807
12	Big-end bearing kit	859807
12	Big-end bearing kit	859949
13	Main bearing kit	859791
13	Main bearing kit	859945
13	Main bearing kit	859791
13	Main bearing kit	859945
14	Thrust washer kit	3580720
14	Thrust washer kit	3580720
15	Flywheel	3580813
15	Flywheel	3580813
16	Ring gear	859720
16	Ring gear	859720
17	Screw	859721
17	Screw	859721
18	Pulley	3581332
18	Pulley	3581332
19	Screw	859762
19	Screw	859762
20	Screw	11997812
20	Screw	11997812
21	Ring	861592
21	Spacer	859764
22	Lock	859765
22	Lock	861593
23	Gear pulley	3581331
23	Gear pulley	3581331
24	Key	3581330
24	Key	3581330
25	Vibration damper	854345
25	Vibration damper	854345
26	Shoulder screw	859710
26	Shoulder screw	859710
