| # | Наименование | Код | |
| 1 | 0001024569 | ||
| 2 | turbine housing | 0001024570 | |
| 3 | Rotor | 837076 | |
| 4 | bearing housing | 0001024572 | |
| 5 | Turbine rotor | 422659 | |
| 6 | piston ring | 0001024574 | |
| 7 | Thrust ring | 467026 | |
| 8 | Spacer sleeve | 422660 | |
| 9 | bearing | 0001024577 | |
| 10 | Ring retainer | 422661 | |
| 11 | Lock ring | 417727 | |
| 12 | sleeve | 0001024580 | |
| 13 | thrust bearing | 0001024581 | |
| 14 | Splash plate | 422662 | |
| 15 | Cover | 420466 | |
| 16 | o-ring | 0001024584 | |
| 17 | Lock ring | 420467 | |
| 18 | Compressor wheel | 837079 | |
| 19 | Nut | 1518784 | |
| 20 | Gasket | 417378 | |
| 21 | Gasket | 417381 | |
| 22 | turbin backplate | 0001024590 | |
| 23 | Lock ring | 422360 | |
| 24 | housing | 0001024592 | |
| 25 | Clamp | 422667 | |
| 26 | 0001024594 | ||
| 27 | Gasket | 417382 | |
| 28 | Plug | 961896 | |
| 29 | Gasket | 957188 | |
| 30 | Hexagon screw | 955524 | |
| 31 | Spring washer | 941907 | |
| 32 | O-ring | 955984 | |
| 35 | Repair kit | 837080 |
