| # | Наименование | Код | |
| 1 | Alternator | 77616 | |
| 2 | housing | 000798340 | |
| 3 | pole shoe | 000798341 | |
| 4 | Field winding | 77771 | |
| 5 | Field winding | 77772 | |
| 6 | Field winding | 77773 | |
| 7 | Field winding | 77774 | |
| 8 | Cross recessed screw | 956116 | |
| 9 | Insulating strip | 72393 | |
| 10 | 000798348 | ||
| 11 | 000798349 | ||
| 12 | 000798350 | ||
| 13 | Screw | 241147 | |
| 14 | Spring washer | 941905 | |
| 15 | 000798353 | ||
| 16 | 000798354 | ||
| 17 | Washer | 77793 | |
| 18 | Ball bearing | 181176 | |
| 19 | 000798357 | ||
| 20 | 000798358 | ||
| 21 | Adjusting washer | 48229 | |
| 21 | Adjusting washer | 48228 | |
| 22 | Ball bearing | 18535 | |
| 23 | Woodruff key | 910115 | |
| 24 | Spring washer | 941911 | |
| 25 | Hexagon nut | 955804 | |
| 26 | Bearing | 77777 | |
| 27 | Gasket | 48212 | |
| 28 | 000798367 | ||
| 29 | Retainer | 77781 | |
| 29 | Retainer | 77780 | |
| 29 | Retainer | 77778 | |
| 29 | Retainer | 77779 | |
| 30 | Screw | 233173 | |
| 31 | Spring washer | 941905 | |
| 32 | Washer | 906822 | |
| 33 | Insulating washer | 120023 | |
| 34 | Isolation | 18192 | |
| 35 | Isolation plate | 72397 | |
| 36 | Carbon brush set | 238038 | |
| 37 | Brush spring | 77783 | |
| 38 | -BRUSH to D- | 000798381 | |
| 38 | +brush to d+ | 000798380 | |
| 39 | Screw | 870850 | |
| 40 | Spring washer | 941905 | |
| 41 | Terminal box | 77787 | |
| 42 | Screw | 116435 | |
| 43 | 000798386 | ||
| 44 | Cross recessed screw | 956058 | |
| 45 | Washer | 241294 | |
| 46 | Cross recessed screw | 956083 | |
| 47 | Spring washer | 941905 | |
| 48 | Screw | 870850 | |
| 49 | Spring washer | 941905 | |
| 50 | Cover | 77788 | |
| 51 | Brace | 77789 | |
| 52 | Cross recessed screw | 956080 | |
| 53 | Spring washer | 941905 | |
| 54 | 000798397 | ||
| 55 | Woodruff key | 910115 | |
| 56 | Hexagon screw | 940101 | |
| 57 | Spring washer | 941906 | |
| 58 | Hexagon nut | 955781 | |
| 59 | Fan | 72406 | |
| 60 | Screw | 233173 | |
| 61 | Spring washer | 941905 | |
| 62 | Washer | 906822 | |
| 63 | 000798406 | ||
| 64 | Cross recessed screw | 956074 | |
| 65 | Spring washer | 941905 |
