| # | Наименование | Код | |
| 1 | Heat exchanger | 3586706 | |
| 11A | Spacer | 3850090 | |
| 13A | Spacer sleeve | 843122 | |
| 2 | Cardboard tube | 3581033 | |
| 3 | O-ring | 925027 | |
| 4 | Gasket | 964106 | |
| 5 | Hexagon screw | 963567 | |
| 6 | Sealing strip | 860127 | |
| 7 | Plug | 861551 | |
| 8 | Bracket | 860391 | |
| 9 | Bracket | 860392 | |
| 10 | Stay | 3581467 | |
| 11 | Flange screw | 946440 | |
| 12 | Flange lock nut | 948645 | |
| 13 | Flange screw | 965226 | |
| 13 | Spacer | 861554 | |
| 14 | Toothed washer | 940143 | |
| 15 | Support ring | 838733 | |
| 16 | Stay | 860450 | |
| 17 | Flange screw | 945444 | |
| 18 | Flange lock nut | 948645 | |
| 19 | Flange screw | 965193 | |
| 20 | Stud | 953002 | |
| 21 | Flange nut | 971095 | |
| 22 | Stud | 17378 | |
| 23 | Flange nut | 971095 | |
| 24 | Hose | 3581099 | |
| 25 | Hose clamp | 994562 | |
| 26 | Hose clamp | 994559 | |
| 27 | Hose | 861109 | |
| 28 | Hose clamp | 994562 | |
| 29 | Hose | 861340 | |
| 30 | Hose clamp | 994561 | |
| 31 | Hose | 861341 | |
| 32 | Hose clamp | 994561 | |
| 33 | Expansion tank | 3580941 | |
| 34 | Stud | 953003 | |
| 34 | Stud | 953005 | |
| 35 | Bracket | 3581040 | |
| 36 | Flange nut | 971095 | |
| 37 | Flange screw | 946544 | |
| 38 | Spacer sleeve | 3581032 | |
| 39 | Spacer sleeve | 3285120 | |
| 40 | Washer | 976944 | |
| 41 | Flange screw | 968999 | |
| 42 | Hose | 942700 | |
| 43 | Hose clamp | 945652 | |
| 44 | Hose | 942700 | |
| 45 | Pressure cap | 1674083 | |
| 46 | Flange screw | 967949 | |
| 47 | Clamp | 952627 |
