| # | Наименование | Код | |
| 1 | parts not sold separately | 0003947960 | |
| 1 | Coolant pump | 3803844 | |
| 2 | Hex. socket screw | 959229 | |
| 3 | Rubber moulding | 8131097 | |
| 4 | Flange screw | 984752 | |
| 5 | Flange screw | 946472 | |
| 6 | Coolant pump housing | 3808593 | |
| 7 | Hose nipple | 977508 | |
| 8 | Rubber moulding | 20430678 | |
| 9 | Coolant pipe | 21253761 | |
| 9 | Coolant pipe | 3836307 | |
| 10 | O-ring | 975675 | |
| 11 | Flange screw | 984744 | |
| 12 | Coolant pipe | 3837621 | |
| 13 | Plug | 982365 | |
| 14 | Flange screw | 984735 | |
| 15 | Sealing ring | 471637 | |
| 16 | Connection pipe | 20451178 | |
| 17 | Sealing ring | 1547254 | |
| 18 | Connection pipe | 20555313 | |
| 19 | Flange screw | 973924 | |
| 20 | Flange screw | 984733 | |
| 21 | Lock brace | 20844430 | |
| 22 | Plug | 20845995 | |
| 23 | Sealing ring | 1547252 | |
| 24 | Sealing strip | 20479636 | |
| 25 | Cover | 21429711 | |
| 26 | Flange screw | 984734 | |
| 27 | Thermostat | 21264664 | |
| 28 | Coolant pipe | 3836308 | |
| 29 | Clamp | 947457 | |
| 30 | Flange screw | 967949 | |
| 31 | Coolant pipe | 3836309 | |
| 32 | Sealing ring | 1547253 | |
| 33 | Gasket | 864491 | |
| 34 | Hose nipple | 977508 | |
| 35 | Cardboard tube | 842235 |
