| # | Наименование | Код | |
| 1 | Intercooler | 3889393 | |
| 1 | Intercooler | 3889391 | |
| 2 | Housing | 21692360 | |
| 2 | Housing | 21692360 | |
| 3 | Kit | 3889405 | |
| 3 | Kit | 3889405 | |
| 4 | Screw | 3838337 | |
| 4 | Screw | 3838337 | |
| 5 | O-ring | 3838406 | |
| 5 | O-ring | 3838406 | |
| 6 | Tube | 3583638 | |
| 6 | Insert | 3808746 | |
| 7 | Spacer | 3838407 | |
| 7 | Spacer | 3838407 | |
| 8 | Cover | 3583629 | |
| 8 | Cover | 3583629 | |
| 9 | O-ring | 3838406 | |
| 9 | O-ring | 3838406 | |
| 10 | Draining nipple | 3583822 | |
| 10 | Draining nipple | 3583822 | |
| 11 | Anode | 838929 | |
| 11 | Anode | 838929 | |
| 12 | Plug | 838928 | |
| 12 | Plug | 838928 | |
| 13 | Screw | 3838337 | |
| 13 | Screw | 3838337 | |
| 14 | Gasket | 3583634 | |
| 14 | Gasket | 3583634 | |
| 15 | Cover | 3583633 | |
| 15 | Cover | 3583633 | |
| 16 | Screw | 3583635 | |
| 16 | Screw | 3583635 | |
| 17 | Connection pipe | 3582786 | |
| 17 | Connection pipe | 3582786 | |
| 18 | Stud | 953049 | |
| 18 | Stud | 953049 | |
| 19 | Flange nut | 945408 | |
| 19 | Flange nut | 945408 | |
| 20 | Flange screw | 965216 | |
| 20 | Flange screw | 965216 | |
| 21 | Flange screw | 947760 | |
| 21 | Flange screw | 947760 | |
| 22 | Hose | 865747 | |
| 22 | Hose | 865747 | |
| 23 | Hose clamp | 994565 | |
| 23 | Hose clamp | 943480 | |
| 24 | Flange screw | 973924 | |
| 24 | Flange screw | 973924 | |
| 25 | Bracket | 3848536 | |
| 25 | Bracket | 3848536 | |
| 26 | Flange screw | 946173 | |
| 26 | Flange screw | 946173 | |
| 27 | Clamp | 984474 | |
| 27 | Clamp | 984474 | |
| 28 | Flange screw | 946440 | |
| 28 | Flange screw | 946440 | |
| 29 | Hose clamp | 943478 | |
| 29 | Hose clamp | 943478 | |
| 30 | Hose | 3583016 | |
| 30 | Hose | 3583016 | |
| 31 | Hose | 942754 | |
| 31 | Hose | 942754 |
