# | Наименование | Код | |
1 | Cylinder head | 3803856 | |
1 | Cylinder head, exch | 3803986 | |
2 | Cap plug | 946780 | |
2 | Cap plug | 946780 | |
3 | Cap plug | 946779 | |
3 | Cap plug | 946779 | |
4 | 6 point socket screw | 986322 | |
4 | Flange screw | 965212 | |
5 | Flange screw | 982761 | |
5 | Plug | 981713 | |
6 | Inlet valve, intake | 8631650 | |
6 | Plug | 981713 | |
6 | Exhaust valve, exhaust | 8631651 | |
7 | Valve spring washer | 8631655 | |
7 | Valve stem seal | 8631652 | |
8 | Valve stem seal | 8631652 | |
8 | Valve spring | 8631656 | |
9 | Valve spring | 8631656 | |
9 | Valve spring washer | 8631655 | |
10 | Valve spring washer | 8631654 | |
10 | Valve spring washer | 8631654 | |
11 | Valve collet | 9454613 | |
11 | Valve collet | 9454613 | |
12 | Inlet valve, intake | 8631650 | |
12 | Exhaust valve, exhaust | 8631651 | |
12 | Pivot | 31251885 | |
13 | Tappet | 8670045 | |
13 | Oil filler cap | 3819129 | |
14 | Valve cover | 8692397 | |
14 | O-ring | 30677740 | |
15 | Camshaft position se | 8631533 | |
15 | Spare parts kit | 21283437 | |
15 | Inlet pipe | 30743258 | |
15 | Inlet pipe | 0003055641 | |
16 | Gasket | 30713459 | |
16 | 6 point socket screw | 986214 | |
17 | Sensor | 8658726 | |
17 | 6 point socket screw | 982483 | |
18 | 6 point socket screw | 982484 | |
18 | Flange screw | 946544 | |
19 | 6 point socket screw, intake | 982486 | |
19 | 6 point socket screw | 982486 | |
20 | Flange screw | 0003055606 | |
20 | 6 point socket screw | 987349 | |
21 | Oil filler cap | 1275403 | |
21 | 6 point socket screw | 982484 | |
22 | 6 point socket screw | 982483 | |
22 | Gasket | 8642665 | |
23 | Gasket | 8692438 | |
23 | Shutter | 30777650 | |
24 | Sealing ring | 8631561 | |
24 | Flange screw | 977814 | |
25 | Screw, cylinder head | 9497825 | |
25 | Stop bracket | 3840206 | |
26 | Cylinder head gasket | 30731263 | |
26 | Cylinder head gasket | 30731261 | |
26 | Gasket | 30650525 | |
26 | Cylinder head gasket | 30731262 | |
26 | Gasket | 30650524 | |
26 | Protecting sleeve | 3884720 | |
27 | Cylinder head gasket | 30731261 | |
27 | Sealing compound | 1161771 | |
27 | Sealing compound | 1161059 | |
27 | Cylinder head gasket | 30731262 | |
27 | Cylinder head gasket | 30731263 | |
27 | Cylinder head gasket | 30731265 | |
27 | Cylinder head gasket | 30731264 | |
28 | Glow plug | 8631607 | |
28 | Sealing compound | 1161059 | |
28 | Sealing compound | 1161771 | |
29 | O-ring | 30756062 | |
29 | O-ring | 30756062 | |
30 | Stud bolt | 30731216 | |
30 | Stud bolt | 30731216 | |
31 | Ball stud | 3812606 | |
31 | Ball stud | 3812606 | |
32 | Glow plug | 8631607 | |
33 | Sealing ring | 8631561 | |
34 | Screw, cylinder head | 9497825 | |
35 | Pivot | 31251885 | |
36 | Tappet | 8670045 | |
37 | Gasket | 860105 | |
38 | Cover | 3584329 | |
39 | Flange screw | 977814 |
