| # | Наименование | Код | |
| 1 | Intercooler | 21506789 | |
| 2 | Housing | 00088024 | |
| 3 | Cover | 00088025 | |
| 4 | Cover | 00088026 | |
| 5 | Cooling element | 00088027 | |
| 6 | Spacer | 3826782 | |
| 7 | Screw | 3838337 | |
| 8 | O-ring | 3826783 | |
| 9 | Draining nipple | 3583822 | |
| 10 | Plug | 838928 | |
| 11 | Anode | 838929 | |
| 12 | Nipple | 3889545 | |
| 13 | Gasket | 947282 | |
| 14 | Bracket | 00088036 | |
| 15 | Flange screw | 946671 | |
| 16 | Hose | 00088038 | |
| 17 | Hollow screw | 00088039 | |
| 18 | Clamp | 00088040 | |
| 19 | Flange screw | 00088041 | |
| 20 | Bracket | 00088042 | |
| 21 | Flange screw | 984753 | |
| 22 | Flange screw | 984766 | |
| 23 | Bracket | 21716932 | |
| 24 | Flange screw | 984735 | |
| 25 | Spacer sleeve | 848694 | |
| 26 | Flange screw | 996676 | |
| 27 | Hose | 21832376 | |
| 28 | Charge air pipe | 21611996 | |
| 29 | V-band clamp | 20592783 | |
| 30 | Charge air pipe | 21611628 | |
| 31 | Hose clamp | 996675 | |
| 32 | O-ring | 945512 | |
| 33 | Flange screw | 984735 | |
| 34 | Drain valve | 22184469 | |
| 35 | Washer | 861917 | |
| 36 | Hose | 969015 |
