| # | Наименование | Код | |
| 1 | Upper section | 847312 | |
| 2 | Elbow nipple | 180283 | |
| 3 | Expansion tank | 845436 | |
| 4 | Cover | 334687 | |
| 5 | Hose | 192618 | |
| 6 | Bracket | 847411 | |
| 7 | Hexagon screw | 940160 | |
| 8 | Spring washer | 941909 | |
| 9 | Bracket | 847410 | |
| 10 | Hexagon screw | 955562 | |
| 11 | Spring washer | 940280 | |
| 12 | Hexagon screw | 955524 | |
| 13 | Spring washer | 941907 | |
| 14 | Hexagon nut | 955826 | |
| 15 | Bracket | 965553 | |
| 16 | Hexagon screw | 955517 | |
| 17 | Washer | 418531 | |
| 18 | Rubber bushing | 403877 | |
| 19 | Spacer sleeve | 403894 | |
| 20 | Washer | 960140 | |
| 21 | Spacer sleeve | 836838 | |
| 22 | Spring washer | 941906 | |
| 23 | Hexagon nut | 955825 | |
| 24 | Riser | 820800 | |
| 25 | Gasket | 420171 | |
| 26 | Plug | 952077 | |
| 27 | Hexagon screw | 955525 | |
| 27 | Hexagon screw | 940159 | |
| 28 | Spring washer | 941907 | |
| 29 | Coolant pipe | 847368 | |
| 30 | Rubber hose | 952979 | |
| 31 | Hose clamp | 943479 | |
| 32 | Hose | 952980 | |
| 33 | Hose clamp | 943480 | |
| 34 | End plate | 806580 | |
| 35 | Plug | 952079 | |
| 36 | Bracket | 965562 | |
| 37 | Clamp | 945734 | |
| 38 | Hexagon screw | 940100 | |
| 39 | Washer | 955893 | |
| 40 | Hexagon nut | 955825 | |
| 41 | Hose attachment | 801163 | |
| 42 | Hose | 952973 | |
| 43 | Hose clamp | 994561 | |
| 44 | Coolant pipe | 847372 | |
| 45 | Hose | 858471 | |
| 46 | Hose clamp | 994562 | |
| 47 | Coolant pipe | 847373 | |
| 48 | Hose hook | 837670 | |
| 49 | Hose clamp | 994561 | |
| 50 | Shut-off cock | 947893 | |
| 51 | Plug | 823369 | |
| 52 | Gasket | 469328 | |
| 53 | Hollow screw | 944213 | |
| 54 | Gasket | 190957 | |
| 55 | Bracket | 965538 | |
| 56 | Hexagon screw | 959798 | |
| 57 | Spring washer | 942336 | |
| 58 | Spacer ring | 912128 | |
| 59 | Clamp | 952633 | |
| 60 | Hexagon screw | 940117 | |
| 61 | Washer | 960140 | |
| 62 | Spacer sleeve | 930419 | |
| 63 | Spring washer | 941906 | |
| 64 | Hexagon nut | 955825 | |
| 65 | Clamp | 945081 | |
| 66 | Hexagon screw | 955523 | |
| 67 | Spring washer | 941907 | |
| 68 | Elbow nipple | 180283 | |
| 69 | Rubber hose | 943367 | |
| 70 | Hose nipple | 961610 | |
| 71 | Rubber hose | 943369 | |
| 72 | Hose clamp | 994559 | |
| 73 | Hose clamp | 994556 | |
| 74 | Plug | 836268 | |
| 75 | Gasket | 947282 |
