| # | Наименование | Код | |
| 1 | Oil cooler | 861601 | |
| 1 | Oil cooler | 861600 | |
| 1 | Oil cooler | 860635 | |
| 1 | Oil cooler | 860633 | |
| 2 | Housing | 0001856815 | |
| 2 | Housing | 0001856824 | |
| 2 | Housing | 0001856874 | |
| 2 | Housing | 0001856885 | |
| 3 | Insert | 860636 | |
| 3 | Insert | 3580868 | |
| 3 | Insert | 3580869 | |
| 3 | Insert | 860634 | |
| 4 | O-ring | 948981 | |
| 4 | O-ring | 948981 | |
| 4 | O-ring | 3581070 | |
| 4 | O-ring | 3581070 | |
| 5 | Gasket | 842597 | |
| 5 | Gasket | 842597 | |
| 5 | End plate | 3580867 | |
| 5 | End plate | 3580867 | |
| 6 | Hex. socket screw | 959224 | |
| 6 | Hex. socket screw | 959224 | |
| 6 | End cover | 842602 | |
| 6 | End cover | 842602 | |
| 7 | Washer | 3580870 | |
| 7 | Washer | 3580870 | |
| 7 | Flange | 842596 | |
| 7 | Flange | 842596 | |
| 8 | End plate | 3580866 | |
| 8 | End plate | 3580866 | |
| 8 | Hexagon screw | 955297 | |
| 8 | Hexagon screw | 955297 | |
| 9 | Spring washer | 941907 | |
| 9 | Spring washer | 941907 | |
| 10 | Shut-off cock | 949918 | |
| 10 | Shut-off cock | 949918 | |
| |$2 | Installation Instruction 7734238 | 0001856826 |
