Lower Gear Unit Sail Boat Drive Unit S120C: 853657

1 1 1 2 2 2 3 3 3 35A 35A 35A 4 4 4 5 5 5 6 6 6 7 7 7 8 8 8 9 9 9 10 10 10 11 11 11 11 11 11 11 11 11 11 11 11 12 12 12 13 13 13 14 14 14 15 15 15 16 16 16 17 17 17 18 18 18 19 19 19 20 20 20 21 21 21 22 22 22 22 22 22 22 22 22 22 22 22 23 23 23 24 24 24 25 25 25 26 26 26 27 27 27 28 28 28 29 29 29 30 30 30 31 31 31 32 32 32 33 33 33 34 34 34 35 35 35 35 35 35 36 36 36 37 37 37 38 38 38

#	Наименование	Код
1	Lower gear	853657
1	Lower gear	853657
1	Lower gear	853657
2	Housing	853555
2	Housing	853555
2	Housing	853555
3	Bearing housing	851647
3	Bearing housing	851647
3	Bearing housing	851647
35A	Hex. socket screw	851860
35A	Hex. socket screw	851860
35A	Hex. socket screw	851860
4	Countershaft	852484
4	Countershaft	852484
4	Countershaft	852484
5	ring	000223316
5	ring	000223937
5	ring	000223628
6	Cone	183752
6	Cone	183752
6	Cone	183752
7	Cup	183750
7	Cup	183750
7	Cup	183750
8	Lock nut	852485
8	Lock nut	852485
8	Lock nut	852485
9	Pretensioning sleeve	851974
9	Pretensioning sleeve	851974
9	Pretensioning sleeve	851974
10	Spacer sleeve	852162
10	Spacer sleeve	852162
10	Spacer sleeve	852162
11	Shim	948303
11	Shim	948303
11	Shim	948303
11	Shim	948300
11	Shim	948298
11	Shim	948298
11	Shim	948298
11	Shim	948300
11	Shim	948299
11	Shim	948299
11	Shim	948300
11	Shim	948299
12	Needle bearing	852508
12	Needle bearing	852508
12	Needle bearing	852508
13	Gear set	851649
13	Gear set	851649
13	Gear set	851649
14	Nut	850981
14	Nut	850981
14	Nut	850981
15	Propeller shaft	851652
15	Propeller shaft	851652
15	Propeller shaft	851652
16	Cup	181587
16	Cup	181587
16	Cup	181587
17	Inner ring	181588
17	Inner ring	181588
17	Inner ring	181588
18	Sealing ring	851979
18	Sealing ring	851979
18	Sealing ring	851979
19	O-ring	925256
19	O-ring	925256
19	O-ring	925256
20	Hex. socket screw	946541
20	Hex. socket screw	946541
20	Hex. socket screw	946541
21	Shim	897871
21	Shim	897871
21	Shim	897871
22	Shim	949074
22	Adjusting washer	851980
22	Shim	949074
22	Adjusting washer	851980
22	Shim	949074
22	Adjusting washer	851982
22	Adjusting washer	851981
22	Adjusting washer	851981
22	Adjusting washer	851981
22	Adjusting washer	851982
22	Adjusting washer	851982
22	Adjusting washer	851980
23	Zinc ring kit	876286
23	Zinc ring kit	876286
23	Zinc ring kit	876286
24	Cross recessed screw	949823
24	Cross recessed screw	949823
24	Cross recessed screw	949823
25	Guard plate	851984
25	Guard plate	851984
25	Guard plate	851984
26	Magnetic plug	852904
26	Magnetic plug	852904
26	Magnetic plug	852904
27	O-ring	955974
27	O-ring	955974
27	O-ring	955974
28	O-ring	925256
28	O-ring	925256
28	O-ring	925256
29	Splined sleeve	852724
29	Splined sleeve	852724
29	Splined sleeve	852724
30	cup spring	000223659
30	cup spring	000223347
30	cup spring	000223968
31	outer disc	000223348
31	outer disc	000223969
31	outer disc	000223660
32	inner disc	000223349
32	inner disc	000223970
32	inner disc	000223661
33	thrust washer	000223971
33	thrust washer	000223350
33	thrust washer	000223662
34	adjusting screw	000223663
34	adjusting screw	000223351
34	adjusting screw	000223972
35	Hex. socket screw	963699
35	Locking wire	852669
35	Locking wire	852669
35	Locking wire	852669
35	Hex. socket screw	963699
35	Hex. socket screw	963699
36	Hex. socket screw	963703
36	Hex. socket screw	963703
36	Hex. socket screw	963703
37	Washer	897511
37	Washer	897511
37	Washer	897511
38	Mounting kit	22303438
38	Mounting kit	22303438
38	Mounting kit	22303438
