| # | Наименование | Код | |
| 1 | Radiator | 864891 | |
| 2 | Reduction nipple | 813615 | |
| 3 | Gasket | 969011 | |
| 4 | Filler cap | 21664189 | |
| 5 | Plug | 947660 | |
| 6 | Gasket | 11994 | |
| 7 | Radiator hose | 3807009 | |
| 8 | Radiator hose | 3807006 | |
| 9 | Hose clamp | 961672 | |
| 10 | Hose clamp | 961673 | |
| 11 | Hose clamp | 961667 | |
| 12 | Hose | 192618 | |
| 13 | Rubber hose | 943367 | |
| 14 | Hose clamp | 961663 | |
| 15 | Flange screw | 968436 | |
| 16 | Flange lock nut | 946673 | |
| 17 | Flange nut | 966818 | |
| 18 | Washer | 948556 | |
| 19 | Rubber bushing | 866857 | |
| 20 | Spacer sleeve | 252202 | |
| 21 | Radiator stay | 3589589 | |
| 22 | Lifting plate | 0003694481 | |
| 23 | Radiator protector | 862956 | |
| 24 | Flange screw | 984738 | |
| 25 | Emblem | 846118 | |
| 26 | Cross recessed sunk | 941651 | |
| 27 | Fan shroud | 3829665 | |
| 28 | Flange screw | 984725 | |
| 29 | Flange nut | 990939 | |
| 30 | Fan guard | 3825685 | |
| 31 | Flange screw | 984736 | |
| 32 | Spacer sleeve | 843075 | |
| 33 | Plastic plug | 845422 | |
| 34 | Radiator bracket | 3589595 | |
| 35 | Flange screw | 984816 | |
| 36 | Flange lock nut | 971099 | |
| 37 | Shut-off cock | 966871 | |
| 38 | Cable tie | 948211 |
