| # | Наименование | Код | |
| 1 | Heat exchanger | 3843533 | |
| 1 | Heat exchanger | 0003052961 | |
| 10A | Hex. socket screw | 942001 | |
| 16A | Riser, hose connecting | 3830257 | |
| 16B | Riser, hose connecting | 3830255 | |
| 2 | Heat exchanger housi | 0003053004 | |
| 2 | Heat exchanger | 3827954 | |
| 28A | Flange screw | 965180 | |
| 3 | Insert | 3830696 | |
| 3 | Insert | 3830696 | |
| 4 | O-ring | 3826783 | |
| 4 | O-ring | 3826783 | |
| 5 | Plug | 982364 | |
| 5 | Plug | 982364 | |
| 6 | Gasket | 836169 | |
| 6 | Gasket | 836169 | |
| 7 | Zinc anode | 823661 | |
| 7 | Zinc anode | 823661 | |
| 8 | Plug | 823662 | |
| 8 | Plug | 823662 | |
| 9 | Plug | 982363 | |
| 9 | Plug | 982363 | |
| 10 | Hex. socket screw | 959224 | |
| 10 | Hex. socket screw | 959224 | |
| 11 | End plate | 3830697 | |
| 11 | Hex. socket screw | 942001 | |
| 12 | End plate | 3830697 | |
| 12 | Spacer | 3830694 | |
| 13 | Shut-off cock | 949918 | |
| 13 | Spacer | 3830694 | |
| 14 | Gasket | 843584 | |
| 14 | Shut-off cock | 949918 | |
| 15 | Gasket | 843584 | |
| 15 | Flange screw | 946173 | |
| 16 | Water pipe, oil cooler-rev.gear | 0003052977 | |
| 16 | Flange screw | 946173 | |
| 17 | Bracket | 865377 | |
| 17 | Water pipe, oil cooler-rev.gear | 0003053019 | |
| 18 | Riser, hose connecting | 3830257 | |
| 18 | Bracket | 865376 | |
| 19 | Riser, hose connecting | 3830255 | |
| 19 | Flange screw | 946752 | |
| 20 | Flange screw | 965220 | |
| 20 | Bracket | 865377 | |
| 21 | Bracket | 865376 | |
| 21 | Flange screw | 965188 | |
| 22 | Bracket | 3827441 | |
| 22 | Flange screw | 946752 | |
| 23 | Flange screw | 965220 | |
| 23 | Flange screw | 965217 | |
| 24 | Flange screw | 948217 | |
| 24 | Flange screw | 965188 | |
| 25 | Bracket | 3827441 | |
| 25 | Sealing ring | 1547253 | |
| 26 | Flange screw | 965217 | |
| 26 | Coolant pipe, charge air cooler | 865930 | |
| 27 | Gasket | 864491 | |
| 27 | Flange screw | 948217 | |
| 28 | Pipe connection | 865821 | |
| 28 | Sealing ring | 1547253 | |
| 29 | O-ring | 925069 | |
| 29 | Coolant pipe, charge air cooler | 865930 | |
| 30 | Coolant pipe, charge air cooler | 3832829 | |
| 30 | Gasket | 864491 | |
| 31 | Pipe connection | 865821 | |
| 31 | Coolant pipe | 3832856 | |
| 32 | Flange screw | 965180 | |
| 32 | Flange lock nut | 948645 | |
| 33 | Bracket | 3832830 | |
| 33 | O-ring | 925069 | |
| 34 | Flange screw | 945444 | |
| 34 | Coolant pipe, charge air cooler | 3832829 | |
| 35 | Coolant pipe | 3832856 | |
| 35 | Coolant pipe, therm. housing | 3832833 | |
| 36 | Coolant pipe, circulation pump | 3837473 | |
| 36 | Flange lock nut | 948645 | |
| 37 | Bracket | 3832830 | |
| 37 | Flange screw | 946471 | |
| 38 | Flange screw | 945444 | |
| 39 | Coolant pipe, therm. housing | 3832833 | |
| 40 | Coolant pipe, circulation pump | 3837473 | |
| 41 | Flange screw | 946471 | |
| 42 | Cardboard tube | 3827303 | |
| 43 | O-ring | 925255 | |
| 44 | Flange screw | 946173 |
