Intake Manifold Upper

Product image
1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 7 7 7 8 8 8 9 9 9 10 10 10 11 11 11 11 11 11 12 12 12 13 13 13 13 14 14 14 15 15 15 16 16 16 17 17 17 18 18 18 19 19 19 20 20 20 21 21 21 22 22 22 23 23 23 24 24 24 25 25 25 26 26 26 27 27 27 28 28 28 29 29 29 30 30 30 31 31 31 32 32 32 33 33 33 33 34 34 34 35 35 35 36 36 36 37 37 37 38 38 38 39 39 39 40 40 40 41 41 41 42 42 42 43 43 43 44 44 44 45 45 45 46 46 46 47 47 47 48 48 48 49 49 49 50 50 50 51 51 51 52 52 52 53 53 53 54 54 54 55 55 55 56 56 56 57 57 57 58 58 58
# Наименование Код
1 Engine control modul, GSI 3855765
1 Engine control modul, GSI 3855764
1 Engine control modul 3855763
2 Screw, ECM to bracket 3855578
2 Screw, ECM to bracket 3855578
2 Screw, ECM to bracket 3855578
3 Flange screw, knock sensor 3852115
3 Flange screw, knock sensor 3852115
3 Flange screw, knock sensor 3852115
4 Module 3854521
4 Module 3854521
4 Module 3854521
5 Screw 3852048
5 Screw 3852048
5 Screw 3852048
6 Anchor, throttle cable 3850266
6 Anchor, throttle cable 3850266
6 Anchor, throttle cable 3850266
7 Bracket, throttle cable 3854569
7 Bracket, throttle cable 3854569
7 Bracket, throttle cable 3854569
8 Bracket, ECU & throttle lever to manifold 3851988
8 Bracket, ECU & throttle lever to manifold 3851988
8 Bracket, ECU & throttle lever to manifold 3851988
9 Bracket, clamp, fuel line to intake manifold 3854820
9 Bracket, clamp, fuel line to intake manifold 3854820
9 Bracket, clamp, fuel line to intake manifold 3854820
10 Bushing, shaft, throttle lever pivot 3852094
10 Bushing, shaft, throttle lever pivot 3852094
10 Bushing, shaft, throttle lever pivot 3852094
11 Clamp, hose, reservoir to pulse limiter 3852170
11 Clamp, hose, reservoir to pulse limiter 3852170
11 Hose clamp, hose, reservoir to pulse limiter 3852529
11 Clamp, hose, reservoir to pulse limiter 3852170
11 Hose clamp, hose, reservoir to pulse limiter 3852529
11 Hose clamp, hose, reservoir to pulse limiter 3852529
12 Clamp, fuel line to bracket 3854896
12 Clamp, fuel line to bracket 3854896
12 Clamp, fuel line to bracket 3854896
13 Filter 3854669
13 Filter 3854669
13 Filter 3854669
13 Cover, flame arrestor 3856226
14 Elbow, pulse limiter to intake manifold 3854675
14 Elbow, pulse limiter to intake manifold 3854675
14 Elbow, pulse limiter to intake manifold 3854675
15 Gasket, throttle body 3854520
15 Gasket, throttle body 3854520
15 Gasket, throttle body 3854520
16 Hose, reservoir to pulse limiter 3853582
16 Hose, reservoir to pulse limiter 3853582
16 Hose, reservoir to pulse limiter 3853582
17 Hose, regulator to intake manifold 3854677
17 Hose, regulator to intake manifold 3854677
17 Hose, regulator to intake manifold 3854677
18 Intermediate lever, to ECM module & throttle lever bracket 3854741
18 Intermediate lever, to ECM module & throttle lever bracket 3854741
18 Intermediate lever, to ECM module & throttle lever bracket 3854741
19 Pin, throttle cable lever 3854742
19 Pin, throttle cable lever 3854742
19 Pin, throttle cable lever 3854742
20 Pin, throttle cable lever 3854743
20 Pin, throttle cable lever 3854743
20 Pin, throttle cable lever 3854743
21 Nut, pins to throttle cable lever 3854744
21 Nut, pins to throttle cable lever 3854744
21 Nut, pins to throttle cable lever 3854744
22 Impulse limiter, reservoir to intake manifold 3852225
22 Impulse limiter, reservoir to intake manifold 3852225
22 Impulse limiter, reservoir to intake manifold 3852225
23 Link, throttle lever to lever 3854648
23 Link, throttle lever to lever 3854648
23 Link, throttle lever to lever 3854648
24 Exhaust manifold, upper intake 3854514
24 Exhaust manifold, upper intake 3854514
24 Exhaust manifold, upper intake 3854514
25 Nut, shaft, throttle lever pivot 3852005
25 Nut, shaft, throttle lever pivot 3852005
25 Nut, shaft, throttle lever pivot 3852005
26 Nut retainer, lever & pin assy 3852009
26 Nut retainer, lever & pin assy 3852009
26 Nut retainer, lever & pin assy 3852009
27 Nut, anchor, throttle cable to bracket 3852118
27 Nut, anchor, throttle cable to bracket 3852118
27 Nut, anchor, throttle cable to bracket 3852118
28 Nut retainer, screw, throttle lever to throttle body 3852420
28 Nut retainer, screw, throttle lever to throttle body 3852420
28 Nut retainer, screw, throttle lever to throttle body 3852420
29 Nut retainer, flame arrestor to throttle body 3852420
29 Nut retainer, flame arrestor to throttle body 3852420
29 Nut retainer, flame arrestor to throttle body 3852420
30 Nut, throttle pivot shaft to bracket 3853404
30 Nut, throttle pivot shaft to bracket 3853404
30 Nut, throttle pivot shaft to bracket 3853404
31 Nut, link, throttle cable lever to lever 3853729
31 Nut, link, throttle cable lever to lever 3853729
31 Nut, link, throttle cable lever to lever 3853729
32 Flange screw, lever to throttle body 3852053
32 Flange screw, lever to throttle body 3852053
32 Flange screw, lever to throttle body 3852053
33 Decal 3854992
33 Decal 3854991
33 Decal 3854991
33 Decal 3854992
34 Sensor 3853956
34 Sensor 3853956
34 Sensor 3853956
35 Flange screw, bracket, ECM module & throttle pivot 3853398
35 Flange screw, bracket, ECM module & throttle pivot 3853398
35 Flange screw, bracket, ECM module & throttle pivot 3853398
36 Flange screw, throttle lever to throttle body 3853428
36 Flange screw, throttle lever to throttle body 3853428
36 Flange screw, throttle lever to throttle body 3853428
37 Bracket 3854566
37 Bracket 3854566
37 Bracket 3854566
38 Screw, throttle body to manifold 3854651
38 Screw, throttle body to manifold 3854651
38 Screw, throttle body to manifold 3854651
39 Screw, map sensor 3854655
39 Screw, map sensor 3854655
39 Screw, map sensor 3854655
40 Screw, clamp, fuel line to bracket 3854897
40 Screw, clamp, fuel line to bracket 3854897
40 Screw, clamp, fuel line to bracket 3854897
41 Screw, upper to lower intake manifold 3855091
41 Screw, upper to lower intake manifold 3855091
41 Screw, upper to lower intake manifold 3855091
42 Sensor 3850396
42 Sensor 3850396
42 Sensor 3850396
43 Sensor, manifold air temperature (mat) 3854527
43 Sensor, manifold air temperature (mat) 3854527
43 Sensor, manifold air temperature (mat) 3854527
44 Seal, map sensor 3854650
44 Seal, map sensor 3854650
44 Seal, map sensor 3854650
45 Shaft, pivot, throttle cable lever to bracket 3854649
45 Shaft, pivot, throttle cable lever to bracket 3854649
45 Shaft, pivot, throttle cable lever to bracket 3854649
46 Stud, flame arrestor to throttle body 3854671
46 Stud, flame arrestor to throttle body 3854671
46 Stud, flame arrestor to throttle body 3854671
47 Grommet, flame arrestor to throttle body 3854670
47 Grommet, flame arrestor to throttle body 3854670
47 Grommet, flame arrestor to throttle body 3854670
48 Washer, flame arrestor to throttle body 3852184
48 Washer, flame arrestor to throttle body 3852184
48 Washer, flame arrestor to throttle body 3852184
49 Washer, throttle lever to pivot shaft 3852189
49 Washer, throttle lever to pivot shaft 3852189
49 Washer, throttle lever to pivot shaft 3852189
50 Hose, flame arrestor to valve cover 3852435
50 Hose, flame arrestor to valve cover 3852435
50 Hose, flame arrestor to valve cover 3852435
51 Split pin 3852052
51 Split pin 3852052
51 Split pin 3852052
52 Elbow, intake manifold to reg. hose 3854679
52 Elbow, intake manifold to reg. hose 3854679
52 Elbow, intake manifold to reg. hose 3854679
53 Adapter, throttle cable 3850941
53 Adapter, throttle cable 3850941
53 Adapter, throttle cable 3850941
54 Washer, pin, throttle cable to lever 3852193
54 Washer, pin, throttle cable to lever 3852193
54 Washer, pin, throttle cable to lever 3852193
55 Throttle 3854519
55 Throttle 3854519
55 Throttle 3854519
56 Repair kit, throttle body 3855193
56 Repair kit, throttle body 3855193
56 Repair kit, throttle body 3855193
57 Sensor 3855194
57 Sensor 3855194
57 Sensor 3855194
58 Sensor, throttle position 3855296
58 Sensor, throttle position 3855296
58 Sensor, throttle position 3855296
