Купить Бензиновые двигатели 7.4GLPLKD 7.4GLPLKE 7.4GIPLKDCE 7.4GIPLKECE DPX385XLKE DPX415XLKE Fuel System Carburetor для лодочных моторов Volvo Penta в Москве

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 29 29 30 31 32 33 34 35 36 37 38 39

#	Наименование	Код
1	Carburetor	3855957
2	Kit	3854105
3	Gasket, carburetor to adapter	3853451
4	Filter	3854019
5	Diaphragm, accelerator pump, carburetor	3854257
6	Gasket, adapter to intake manifold	3853275
7	Diaphragm	3853991
8	Choke	3854108
9	Float	3853575
10	Cardboard tube, nipple, carburetor	3852082
11	Cable tie, cap-nipple-carburetor assy	3852158
12	Screw, throttle lever	3852074
13	Screw, throttle lever to carburetor	3852154
14	Nut, throttle lever	3853758
15	Nut retainer, throttle lever to carburetor	3852420
16	Washer, electric choke lead	3852191
17	Cable, electric choke	3853845
18	Drain cock, 0.250	3854253
19	Terminal, 0.312	3852037
20	Cover, terminal	3854259
21	Nut, stud, carburetor to adapter	3852142
22	Washer, pin, throttle cable to lever	3852193
23	Split pin, throttle cable	3852052
24	Stud, flame arrestor to carburetor	3853550
25	Connector, hose to flame arrestor	3852695
26	Nut, flame arrestor cover to flame arrestor	3852749
27	Hose, valve cover to flame arrestor	3854666
28	Adapter, carburetor	3853453
29	Decal	3854980
29	Cover, flame arrestor	3850510
29	Decal	3854987
30	Pad, cover, flame arrestor	3850458
31	Screw, adapter to intake manifold	3852864
32	Stud, carburetor to adapter	3853373
33	Flame shield	3854066
34	Intermediate lever, carburetor	3850217
35	Nut, flame arrestor to carburetor	3853561
36	Washer, nut, flame arrestor cover	3852007
37	Screw, throttle lever to carburetor	3850415
38	Adapter, throttle cable	3850941
39	Retainer, throttle cable	3852019
