Fuel System

Product image
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 31 31 32 33 34 34 35 36 37 38 38 39 39 39 40 41 41 42 43 44 45 46 47 48 49 50 51 52 52 53 54 54 55 56 57 58 58 59 60 60 61 62 63 64 64 65 66 67 68 |$30 |$30
# Наименование Код
1 Retainer, float pin 3852034
2 Valve, reservoir assy 3854152
3 Fitting, fuel line to reservoir 3852462
4 Grommet, fuel pump to cover 3852481
5 Adapter, fuel line 3852017
6 O-ring, retainer, fuel pump 3853642
7 Retainer, fuel pump to cover 3853572
8 Bracket, fuel pump grommet 3853573
9 Gasket, cover 3857728
10 Float, reservoir assy 3853575
11 Spring seat, float needle 3853576
12 Gasket, float needle seat 3853577
13 Needle, float 3853578
14 Clip, needle to float 3853579
15 Elbow, vent, reservoir to intake 3853597
16 Elbow, reservoir to thermostat hsg 3852480
17 Screw, cover to reservoir 3853606
18 Protective cap, pressure valve 3853616
19 Fuel pump, high pressure 3857650
20 Reservoir 3854149
21 Plug, reservoir drain 3852167
22 Bracket, fuel pump and relay mounting 3858337
23 Cardboard tube, reservoir assy 3854405
24 Tab washer, circuit breaker 3852001
25 Elbow, inlet, fuel filter cover 3852013
26 Nut, circuit breaker 3852064
27 Screw, relay and cable assy 3852208
28 Hexagon screw, circuit breaker to bracket 3853620
29 Grommet, fuel pump to bracket 3858342
30 Kit 3850861
31 Filter 3852413
31 Clamp, oil withdrawal tube to fuel filter brkt 3853261
31 Spacer sleeve, clamp, oil tube to fuel filter bracket 3852495
32 Nipple, fuel line to fuel pump 856954
33 O-ring, fitting 3850820
34 Nut, stud, bracket to cylinder head 3853273
34 Bracket, cylinder head 3854377
35 Fuel pump, low pressure 3857985
36 Switch, 12.5A 3854282
37 Hose, vapor separator to oil cooler 3855684
38 Fuel pipe, fuel regulator to reservoir 3856970
38 Fuel pipe, fuel regulator to reservoir 3854646
39 Bracket, fuel line clamp 3854820
39 Fuel pipe, lp pump to reservoir 3858225
39 Fuel pipe, lp pump to reservoir 3858226
40 Stud, lift bracket and fuel pump bracket 3852117
41 Nut, screw, fuel filter assy to bracket 3852129
41 Flange screw, fuel filter to bracket 3853326
42 Hose clamp, hose to gimbal 3852098
43 Nut 3852129
44 Relay, fuel pump 3857533
45 Fitting, fuel pump to fuel filter cover 3853493
46 O-ring, fitting, fuel pump to cover 3850819
47 Bracket, relay 3852210
48 Fitting, valve 3854924
49 Hose clamp, hose to reservoir 3852602
50 Kit, fuel reservoir 3850374
51 Protective cap, breaker assy, fuel pump 3853537
52 Bracket, reservoir to flywheel hsg 3854582
52 Bracket, reservoir to flywheel hsg 3850271
53 Impulse limiter 3852225
54 Fuel pipe, hp fuel pump to fuel rail 3857885
54 Fuel pipe, hp fuel pump to fuel rail 3854645
55 Nut, reservoir to bracket 3850657
56 Screw, reservoir to bracket 3853558
57 Clamp, hose to pulse limiter 3852170
58 Hose clamp, hose to pulse limiter 3852529
58 Clamp, hose to pulse limiter 3852170
59 Elbow, pulse limiter to fitting 3854675
60 Hose, reservoir to pulse limiter 3853582
60 Hose, reservoir to pulse limiter 3856944
61 O-ring, fuel line to fuel regulator 3850423
62 O-ring, fuel line to fuel rail 3850424
63 Hose clamp, hose, reservoir 3852602
64 Hose, reservoir to ps oil cooler 3854849
64 Hose, reservoir to ps oil cooler 3854853
65 Hose clamp, hose, ps oil cooler 3852602
66 Flange screw 3853547
67 Module, fuel filter oil tube 3863326
68 Stud 3852117
|$30 Bulletin p-18-8-1 0004048230
|$30 Bulletin P-23-3-4 0004048229
