Flywheel Housing and Mounts

Product image
1 1 2 2 3 3 4 4 5 5 6 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 14 15 15 16 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 23 24 24 25 25 26 26 27 27 28 28 29 29 29 30 30 30 31
# Наименование Код
1 Flywheel housing 3856699
1 Housing 3852831
2 Cover 3854604
2 Primary shaft 873013
3 Gasket 3852834
3 Sealing ring, primary shaft 958859
4 Hose, flywheel hsg 3852832
4 Ball bearing, primary shaft 3851019
5 Snap ring, primary shaft 914533
5 Screw, flywheel cover 3852421
6 Flange screw, flywheel hsg to engine 3853392
6 Flange screw, reservoir and flywheel hsg to engine 3853547
6 Snap ring, primary shaft 914462
7 Tab washer, ground stud, flywheel hsg 3852002
7 Sealing ring, primary shaft 958860
8 Washer, ground stud, flywheel hsg 3852058
8 Cover plate, flywheel housing 854939
9 Hexagon screw, flywheel cover to housing 947224
9 Rubber cushion, engine front 3853805
10 Flange screw 3853547
10 Hexagon screw, rear mount to transom plate 959968
11 Rubber cushion, transom plate 3853806
11 Flange screw, flywheel housing to engine 3850753
12 Washer, rear mount to transom plate 3852155
12 Bushing, primary shaft to crankshaft 3860697
13 Hexagon screw, rear mount 3850930
13 Stud, flywheel housing to engine 3850571
14 Washer 3852058
14 Tab washer 3852002
14 Lock nut, rear mount 3850929
15 Washer, rear mount to flywheel hsg 3852540
15 Nut 3852065
16 Clamping ring kit, flywheel housing 854315
16 Square nut, rear mount 3852539
16 Ring 0004033823
17 Washer, rear mount 3852622
17 Striker plate, clamp ring 806624
18 Washer, rear mount 3852542
18 Hexagon screw 191844
19 Rubber ring 804190
19 Stud, flywheel housing to engine 3852483
20 Nut, terminal to ground stud, flywheel hsg 3852065
20 Washer 3852070
21 Rubber cushion, engine front 3853805
21 Washer, ground stud, flywheel hsg 3852070
22 Bracket, front, port and starboard 3852760
22 Bracket, front, port and starboard 3852760
23 Flange screw, front mount bracket to engine 3853326
23 Flange screw 3853393
23 Flange screw, front mount bracket to engine 3853326
24 Bolt, front mount 3852566
24 Bolt, front mount 3852566
25 Tab washer, bolt, front mount, engine 3852090
25 Washer, bolt, front mount, engine 3852428
26 Washer, front mount 3852433
26 Washer, front mount 3852433
27 Nut, bolt, mount bracket 3852021
27 Nut, bolt, mount bracket 3852021
28 Washer, front mount 3852428
28 Tab washer, front mount 3852090
29 Attaching clamp 3852092
29 Clamp, starter leads to stbd bracket 3852146
29 Clamp 3852434
30 Attaching clamp, engine harness 3852092
30 Clamp, starter leads to stbd bracket 3852146
30 Attaching clamp 3852490
31 Clamp 3853312
