Fuel Pump and Intake Manifold

Product image
1 1 1 1 2 2 3 3 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 33 33 34 34 35 35 36 36 37 37 38 38 39 39 40 40 41 41 42 42 43 43 44 44 45 45 46 46 47 47 48 48 49 49 50 50 51 51 52 52 53 53 54 54 55 55 56 56 57 57 58 58 59 59 60 60 61 61 |$3 |$3 |$3 |$3
# Наименование Код
1 Shield, intake manifold 3856027
1 Inlet pipe 3853890
1 Inlet pipe 3854100
1 Shield, intake manifold 3856027
2 Kit 3850861
2 Kit 3850861
3 Cover 3850835
3 Fuel filter 3851218
3 Fuel filter 3851218
3 Cover 3850835
4 Intake gasket kit 3854096
4 Intake gasket kit 3854095
5 Bolt, intake manifold to head 3853539
5 Bolt, intake manifold to head 3853539
6 Gasket, distributor 3852109
6 Gasket, distributor 3852109
7 Clamp, distributor to engine 3852108
7 Clamp, distributor to engine 3852108
8 Breaker, water temp, intake manifold 3854710
8 Breaker, water temp, intake manifold 3854710
9 Protective cap, breaker assy, fuel pump 3853537
9 Protective cap, breaker assy, fuel pump 3853537
10 Fuel pump, low pressure 3854902
10 Fuel pump, low pressure 3854902
11 Automatic fuse, 12.5A 3854162
11 Automatic fuse, 12.5A 3854162
12 Fitting, fuel line to fuel pump 3853494
12 Fitting, fuel line to fuel pump 3853494
13 O-ring, fuel line to fuel pump, carburetor 3850820
13 O-ring, fuel line to fuel pump, carburetor 3850820
14 Stud, carburetor to adapter 3853373
14 Stud, carburetor to adapter 3853373
15 Fitting, fuel pump to fuel filter cover 3853493
15 Fitting, fuel pump to fuel filter cover 3853493
16 O-ring, fitting, fuel pump to cover 3850819
16 O-ring, fitting, fuel pump to cover 3850819
17 Nut, anchor, throttle cable to bracket 3852118
17 Nut, anchor, throttle cable to bracket 3852118
18 Screw, anchor, throttle cable to bracket 3852048
18 Screw, anchor, throttle cable to bracket 3852048
19 Bracket, throttle cable to manifold 3850220
19 Bracket, throttle cable to manifold 3850227
20 Screw, bracket, throttle anchor 3852086
20 Screw, bracket, throttle anchor 3852086
21 Stud, lift bracket & fuel pump bracket 3852117
21 Stud, lift bracket & fuel pump bracket 3852117
22 Nut, lift bracket 3853404
22 Nut, lift bracket 3853404
23 Fuel pipe, fuel pump to carburetor 3854074
23 Fuel pipe, fuel pump to carburetor 3854073
24 Plug, intake manifold 3852075
24 Plug, intake manifold 3852075
25 Hexagon screw, circuit breaker to bracket 3853620
25 Hexagon screw, circuit breaker to bracket 3853620
26 Clamp 3852434
26 Clamp 3852434
27 Attaching clamp, oil withdrawal tube to fuel filter brkt 3852458
27 Attaching clamp, oil withdrawal tube to fuel filter brkt 3852458
28 Nut, clamp, oil withdrawal tube 3852129
28 Nut, clamp, oil withdrawal tube 3852129
29 Nut, relay to fuel pump mtg bracket 3852077
29 Nut, relay to fuel pump mtg bracket 3852077
30 Screw, relay & cable assy 3852208
30 Screw, relay & cable assy 3852208
31 Bracket, fuel filter and fuel pump 3854376
31 Bracket, fuel filter and fuel pump 3854376
32 Bracket 3852649
32 Bracket 3852649
33 Bracket, throttle cable anchor 3851989
33 Bracket, throttle cable anchor 3851989
33 Anchor, throttle cable 3850266
33 Anchor, throttle cable 3850266
34 Flange screw 3853419
34 Flange screw 3853419
35 Elbow, inlet, fuel filter cover 3852013
35 Elbow, inlet, fuel filter cover 3852013
36 Flange screw, fuel filter assy to bracket 3853326
36 Flange screw, fuel filter assy to bracket 3853326
37 Grommet, fuel pump 3852481
37 Grommet, fuel pump 3852481
38 Flange screw, distributor clamp to engine 3853557
38 Flange screw, distributor clamp to engine 3853557
39 Nut, circuit breaker 3852064
39 Nut, circuit breaker 3852064
40 Nut, stud 3853273
40 Nut, stud 3853273
41 Trunk, fuel pump 3853681
41 Trunk, fuel pump 3853681
42 Bracket, relay 3852210
42 Bracket, relay 3852210
43 Relay 3852259
43 Relay 3852259
44 Cable, fuel pump 3854088
44 Cable, fuel pump 3854088
45 Connector 3852240
45 Connector 3852240
46 Terminal 3852235
46 Terminal 3852235
47 Terminal 3852246
47 Terminal 3852246
48 Terminal 3852247
48 Terminal 3852247
49 Terminal, pin 3852229
49 Terminal, pin 3852229
50 Kit 3852258
50 Kit 3852258
51 Connector, fuel pump 3852260
51 Connector, fuel pump 3852260
52 Terminal, fuel pump 3853679
52 Terminal, fuel pump 3853679
53 Retainer, cable 3852237
53 Retainer, cable 3852237
54 Cable 3854117
54 Cable 3854117
55 Pin connector 3852239
55 Pin connector 3852239
56 Terminal 3852257
56 Terminal 3852257
57 Terminal 3852235
57 Terminal 3852235
58 Connector 3852198
58 Connector 3852198
59 Tab washer, circuit breaker 3852001
59 Tab washer, circuit breaker 3852001
60 Stud, lift bracket 3852093
60 Stud, lift bracket 3852093
61 Cable tie, engine cable to fuel pump assy 3852158
61 Cable tie, engine cable to fuel pump assy 3852158
|$3 Bulletin p-18-8-1 0003978129
|$3 Bulletin p-18-8-1 0003978196
|$3 Bulletin P-23-3-4 0003978195
|$3 Bulletin P-23-3-4 0003978128
