Carburetor

Product image
1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 29 29 29 29 30 30 31 31 32 32 33 33 34 34 35 35 36 36 37 37 38 38 39 39 |$0 |$0
# Наименование Код
1 Carburetor 3854568
1 Carburetor 3850994
2 Repair kit 3855017
2 Kit 3854105
3 Gasket, carburetor to adapter 3853497
3 Gasket, carburetor to adapter 3853451
4 Filter 3854019
4 Filter 3854019
5 Diaphragm, accelerator pump, carburetor 3854257
5 Diaphragm, accelerator pump, carburetor 3854257
6 Gasket, adapter to intake manifold 3853275
6 Gasket, adapter to intake manifold 3853275
7 Diaphragm 3853991
7 Diaphragm 3853991
8 Choke 3854108
8 Choke 3854108
9 Float 3853575
9 Float 3853575
10 Cardboard tube, nipple, carburetor 3852082
10 Cardboard tube, nipple, carburetor 3852082
11 Cable tie, cap-nipple-carburetor assy 3852158
11 Cable tie, cap-nipple-carburetor assy 3852158
12 Screw, throttle lever 3852074
12 Screw, throttle lever 3852074
13 Screw, throttle lever to carburetor 3852154
13 Screw, throttle lever to carburetor 3852154
14 Nut, throttle lever 3853758
14 Nut, throttle lever 3853758
15 Nut retainer, throttle lever to carburetor 3852420
15 Nut retainer, throttle lever to carburetor 3852420
16 Washer, electric choke lead 3852191
16 Washer, electric choke lead 3852191
17 Cable, electric choke 3853845
17 Cable, electric choke 3853845
18 Drain cock, 0.250 3854253
18 Drain cock, 0.250 3854253
19 Terminal, 0.312 3852037
19 Terminal, 0.312 3852037
20 Cover, terminal 3854259
20 Cover, terminal 3854259
21 Nut, stud, carburetor to adapter 3852142
21 Nut, stud, carburetor to adapter 3852142
22 Washer, pin, throttle cable to lever 3852193
22 Washer, pin, throttle cable to lever 3852193
23 Split pin, throttle cable 3852052
23 Split pin, throttle cable 3852052
24 Stud, flame arrestor to carburetor 3853551
24 Stud, flame arrestor to carburetor 3853550
25 Connector, hose to flame arrestor 3852695
25 Connector, hose to flame arrestor 3852695
26 Nut, flame arrestor cover to flame arrestor 3852749
26 Nut, flame arrestor cover to flame arrestor 3852749
27 Hose, valve cover to flame arrestor 3854666
27 Hose, valve cover to flame arrestor 3854666
28 Adapter, carburetor 3853453
28 Adapter, carburetor 3853453
29 Decal 3854980
29 Decal 3850542
29 Decal 3854980
29 Cover, flame arrestor 3850510
29 Cover, flame arrestor 3850510
29 Decal 3850543
30 Pad, cover, flame arrestor 3850458
30 Pad, cover, flame arrestor 3850458
31 Screw, adapter to intake manifold 3852864
31 Screw, adapter to intake manifold 3852864
32 Stud, carburetor to adapter 3853373
32 Stud, carburetor to adapter 3853373
33 Flame shield 3853887
33 Flame shield 3854066
34 Intermediate lever, carburetor 3850217
34 Intermediate lever, carburetor 3850217
35 Nut, flame arrestor to carburetor 3853561
35 Nut, flame arrestor to carburetor 3853561
36 Washer, nut, flame arrestor cover 3852007
36 Washer, nut, flame arrestor cover 3852007
37 Screw, throttle lever to carburetor 3850415
37 Screw, throttle lever to carburetor 3850415
38 Adapter, throttle cable 3850941
38 Adapter, throttle cable 3850941
39 Retainer, throttle cable 3852019
39 Retainer, throttle cable 3852019
|$0 Bulletin P-23-1-1 0003978082
|$0 Bulletin P-23-1-1 0003978039
