Intake Manifold Upper

Product image
1 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 33 33 33 34 34 35 35 36 36 37 37 38 38 39 39 40 40 41 41 41 41 42 42 43 43 44 44 45 45 46 46 47 47 48 49 50 51 51 52 53 54 55 56 57 58 59 60 61 61
# Наименование Код
1 Engine control modul, 7.4 GSi, DPX385 3856943
1 Engine control modul, 8.2 GSi, DPX415 3856979
1 Exhaust manifold, upper 3857685
2 Sensor 3854527
2 Flange screw, ECM to bracket 3852053
3 Cover, EGR opening 3857186
3 Flange screw, knock module 3852115
4 Hexagon screw, EGR cover 3858499
4 Module 3854521
5 Bolt, upper to lower intake 3857473
5 Screw, throttle anchor to bracket 3852048
6 Tube 3857488
6 Anchor, throttle cable 3850266
7 Bracket, throttle cable 3851989
7 Throttle body 3857691
8 Bracket, ECU and throttle lever to manifold 3856949
8 Iac valve 3857696
9 Bracket, clamp, fuel line to intake manifold 3854820
9 O-ring, IAC 3858054
10 Bushing, shaft, throttle lever pivot 3852094
10 Sensor 3857487
11 Screw, IAC and TPS 3857693
11 Clamp, hose, reservoir to pulse limiter 3852170
11 Hose clamp, hose, reservoir to pulse limiter 3852529
12 Gasket, upper to lower intake 3857475
12 Clamp, fuel line to bracket 3854896
13 Flame shield 3856951
13 Gasket, throttle body to intake 3857476
14 Nut, throttle body attachment 3857679
14 Elbow, pulse limiter 3854675
15 Hose clamp, flame arrestor 3852604
15 Gasket, throttle body 3854520
16 Flame shield 3856980
16 Hose, reservoir to pulse limiter 3853582
17 Hose, regulator to intake manifold 3854677
17 Clamp, fuel lines to plenum 3857437
18 Intermediate lever, to ECM and throttle lever bracket 3854741
18 Fitting, pulse limiter elbow to EGR cover 3857436
19 Pin, throttle cable lever 3854742
19 Grommet, ECU bracket 941263
20 Intermediate lever 3854741
20 Pin, throttle cable lever 3854743
21 Nut, pins to throttle cable lever 3854744
21 Link, throttle lever to throttle body 3856974
22 Gasket, EGR cover 3857226
22 Impulse limiter, reservoir to intake manifold 3852225
23 Link, throttle lever to tb lever 3854648
23 Stud, throttle body attachment 3857486
24 Exhaust manifold, upper 3854514
24 Bracket 3856983
25 Nut, shaft, throttle lever pivot 3852005
25 Anchor 3850266
26 Nut retainer, lever and pin assy 3852009
26 Bushing 3852094
27 Nut, anchor, throttle cable to bracket 3852118
27 Nut, throttle 3852005
28 Nut, throttle 3852118
28 Nut retainer, screw, throttle lever to throttle body 3852420
29 Nut, throttle 3853729
29 Nut retainer, flame arrestor to throttle body 3852420
30 Nut, throttle 3854744
30 Nut, throttle pivot shaft to bracket 3853404
31 Retainer, throttle cable 3852019
31 Split pin, throttle 3852052
32 Flange screw, lever to throttle body 3852053
32 Pin, throttle 3857490
33 Decal 3854992
33 Pin, throttle 3854743
33 Decal 3856487
33 Decal 3856486
33 Decal 3855620
34 Swivel, throttle 3857491
34 Nut, throttle pin to bracket 3853404
35 Grommet, ECU bracket 941263
35 Screw, anchor 3852048
36 Flange screw, throttle lever to throttle body 3853428
36 Flange screw, clamp, fuel lines to upper intake 3853398
37 Flange screw, anchor bracket to upper intake 3853398
37 Bracket 3854566
38 Screw, throttle body to manifold 3854651
38 Spacer, throttle lever 3856975
39 Screw, map sensor 3854655
39 Washer, throttle lever 3852189
40 Washer, throttle lever 3852193
40 Screw, clamp, fuel line to bracket 3854897
41 Engine control modul 3858865
41 Engine control modul 3858573
41 Engine control modul 3856914
41 Screw, upper to lower intake manifold 3855091
42 Flange screw, ECU to bracket 3852053
42 Sensor 3850396
43 Bracket, ECU, oil fill 3856949
43 Sensor 3854527
44 Seal, map sensor 3854650
44 Module 3854521
45 Shaft, pivot, throttle cable lever to bracket 3854649
45 Flange screw, knock module 3852115
46 Split pin, throttle body pivot pin 3852052
46 Stud, flame arrestor to throttle body 3854671
47 Grommet, flame arrestor to throttle body 3854670
47 Retainer, throttle cable 3852019
48 Washer, flame arrestor to throttle body 3852184
49 Washer, throttle lever to pivot shaft 3852189
50 Hose clamp, pcv valve hose 3852196
51 Hose, pcv valve 3856945
51 Hose, elbow 3856946
52 Elbow, intake manifold to reg. hose 3854679
53 Adapter, throttle cable 3850941
54 Washer, pin, throttle cable to lever 3852193
55 Split pin, cable to throttle lever assy 3852052
56 Throttle body 3856942
57 Repair kit, throttle body 3855193
58 Repair kit 3855185
59 Sensor, throttle position 3855296
60 Clamp, pulse limiter 3852170
61 Hose, flame arrestor 3852668
61 Plug, manifold, rear plenum 3855033
