Upper Intake Manifold

1 2 3 4 5 6 7 8 9 10 11 12 13 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 35 36 37 38 39 40 41 42 43 44 45 46 46 47 48 49 50 51 51 51 52 53 54 55 56 57 58 59 60 61 62 63 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78

#	Наименование	Код
1	Valve, PCV	3852820
2	Hose clamp, hose, upper intake manifold to filter	3852529
3	Elbow, hose, pcv valve	3852480
4	Nut, stud, throttle body	3852142
5	Flange screw, .TFI module to mounting bracket	3852080
6	Cable tie, eng cbi lead, idle air by connector	3852158
7	Hose clamp, filter hose to intake	3852529
8	Screw, E-coil & bracket to TFI	3852168
9	Hose clamp, hose, filter	3852196
10	Clamp, hose, filter to intake manifold	3852170
11	Hose clamp, hose, map sensor	3852196
12	Hose clamp, hose, reservoir to pulse limiter	3852529
13	Throttle body, Fsi	3855163
13	Shutter housing, Fi	3850768
14	Nut, screw, throttle lever to throttle body	3852077
15	Screw, lever & pin assy to throttle body	3852066
16	Screw, throttle lever to throttle body	3852212
17	Adapter, air bypass solenoid	3853612
18	Gasket, throttle air bypass solenoid	3853613
19	Sensor	3850988
20	Screw, air bypass solenoid	3853614
21	Nut, shoulder, throttle lever	3853627
22	Bracket, throttle body	3850353
23	Screw, throttle sensor	3850986
24	Gasket, adapter to solenoid	3853613
25	Screw, throttle air bypass solenoid	3853614
26	Valve, throttle air bypass	3850987
27	Clip, connector	3853734
28	Filter, adapter, throttle air bypass solenoid	3853748
29	Grommet, pcv valve	3853767
30	Nut, throttle cable	3853729
31	Filter, crankcase vent	3853768
32	Cardboard tube, screw, hex idle air adjustment	3853772
33	Washer, throttle bracket	3852162
34	Bracket, styling cover to TFI/E-coil bracket	3853775
35	Hose	3852377
35	Hose, map sensor to filter	3854903
36	Hose, filter to intake manifold	3852376
37	Screw, E-coil bracket to TFI bracket	3852212
38	Filter, map sensor, vacuum line	3852224
39	Impulse limiter, upper intake manifold	3852225
40	Screw, upper to lower intake manifold, center	3853760
41	Screw, upper to lower intake manifold	3853635
42	Screw, upper to lower intake manifold	3853638
43	Hose, valve cover to arrestor	3853723
44	Bracket, TFI module & E-coil	3853763
45	Hose, reservoir to pulse limiter	3853582
46	Grommet, flame arrestor, to throttle body	3853594
46	Grommet, flame arrestor, to throttle body	3850922
47	Clamp, flame arrestor to throttle body	3853595
48	Hose, pressure regulator	3853765
49	Bracket, ignition coil to TFI bracket	3853625
50	Gasket, TFI/E-coil mounting bracket	3853761
51	Decal	3851032
51	Decal	3854990
51	Decal	3854989
52	Manifold	3854276
53	Stud, throttle body to upper intake manifold	3852176
54	Protective cap, map sensor screw	3853537
55	Fitting, pressure regulator hose	3853639
56	Bracket, styling cover to rear intake manifold	3853762
57	Hose, upper intake manifold to pcv valve	3854904
58	Flange screw, bracket, flame arrestor cover	3853661
59	Control unit	3854139
60	Level sensor	3854272
61	Screw	3854273
62	Control unit	3854274
63	Flame shield, throttle body, FSi	3850915
63	Flame shield, throttle body, Fi	3854144
64	Coil	3854161
65	Retainer, throttle cable	3852019
66	Cover, flame arrestor & throttle body	3853571
67	Screw, flame arrestor clamp	3853722
68	Anchor, throttle cable	3850266
69	Bracket, throttle anchor to intake manifold	3850226
70	Intake gasket, upper to lower intake manifold	3853636
71	Screw, stylint cover bracket	3852207
72	Screw, styling cover to intake manifold	3853764
73	Nut, anchor, throttle cable to bracket	3852118
74	Screw, cable anchor	3852048
75	Sensor, manifold air pressure	3854160
76	Screw, map sensor	3853764
77	Adapter	3850941
78	Nut, throttle cable adapter	3853729
