Steering

Product image
1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 34 34 35 35
# Наименование Код
1 Steering pump, P/S pump to engine 3850491
1 Steering pump, P/S pump to engine 3850491
2 Bracket 3852512
2 Bracket 3852512
3 Washer, pis pump bracket 3852162
3 Washer 3852162
4 Washer, stud, water pump & steering pump 3852162
4 Washer, stud, water pump & steering pump 3852162
5 V-belt, P/S pump 3852464
5 V-belt, P/S pump 3852464
6 Hose assembly, cylinder to oil cooler, P/S 3854168
6 Hose, cylinder to oil cooler, P/S 3854056
7 O-ring, pressure hose to steering pump 3852497
7 O-ring, pressure hose to steering pump 3852497
8 Hose, oil cooler to pump, return 3850644
8 Hose, oil cooler to steering pumo, return 3852839
9 Hose, gimbal to cooler 3852281
9 Hose, reservoir to cooler 3853580
9 Hose 3850283
10 Pulley 3853804
10 Pulley 3853804
11 Hose assembly, steering pump to pressure valve 3853967
11 Hose 3853918
12 Nut, oil cooler & bracket assy 3852079
12 Nut, oil cooler & bracket assy 3852079
13 Spacer, oil cooler, P/S 3853236
13 Spacer, oil cooler, P/S 3853236
14 Screw, oil cooler & bracket assy 3852126
14 Screw, oil cooler & bracket assy 3852126
15 Fitting, steering hoses 3853315
15 Fitting, steering hoses 3853315
16 Cable tie 3852158
16 Cable tie 3852158
17 Oil cooler, P/S 3852840
17 Oil cooler, P/S 3852840
18 Flange screw, P/S cooler clamp to flywheel hsg 3853326
18 Flange screw, P/S cooler clamp to flywheel hsg 3853326
18 Nut, P/S cooler clamp to reservoir 3852177
18 Nut, P/S cooler clamp to reservoir 3852177
19 Clamp, engine oil cooler, P/S 3852218
19 Clamp, engine oil cooler, P/S 3852218
20 Screw, steering pump bracket 3853405
20 Screw, steering pump bracket 3853405
21 Stud, water/steering pump bracket to engine 3852507
21 Stud, water/steering pump bracket to engine 3852507
22 Flange screw, plug lead retainer bracket to cyl head 3853557
22 Flange screw, plug lead retainer bracket to cyl head 3853557
23 Clamp, hoses to cylinder head 3852837
23 Clamp, hoses to cylinder head 3852837
24 Stud, oil cooler clamp to reservoir 3852093
24 Stud, oil cooler clamp to reservoir 3852093
25 Nut retainer, stud, P/S pump bracket 3853403
25 Nut retainer, stud, P/S pump bracket 3853403
26 Nut retainer, stud, P/S pump bracket 3853403
26 Nut retainer, stud, P/S pump bracket 3853403
27 Flange screw, lift bracket/clamp, P/S hoses to head 3853557
27 Flange screw, lift bracket/clamp, P/S hoses to head 3853557
28 Attaching clamp, steering pump hoses to front mount 3852490
28 Attaching clamp, steering pump hoses to front mount 3852490
29 Hose clamp, hose, oil cooler, bypass pipe 3852602
29 Hose clamp, hose, oil cooler, bypass pipe 3852602
30 Hose clamp, hose, P/S pump to oil cooler 3852196
30 Hose clamp, hose, P/S pump to oil cooler 3852196
31 Hose clamp, hose, water to gimbal hsg 3853786
31 Hose clamp, hose, water to gimbal hsg 3853786
32 Hose, cooler to thermostat 3850363
32 Hose, cooler to water pump 3850231
33 Stud, P/S pump bracket to engine 3853402
33 Stud, P/S pump bracket to engine 3853402
34 Washer, stud, P/S pump bracket 3852054
34 Washer, stud, P/S pump bracket 3852054
35 Washer, oil cooler clamp to reservoir 3852058
35 Washer, oil cooler clamp to reservoir 3852058
