| # | Наименование | Код | |
| 1 | Alternator | 3854182 | |
| 1 | Alternator | 3853853 | |
| 1 | Housing, front | 3852647 | |
| 1 | Housing, front | 3852647 | |
| 2 | Rotor | 3854226 | |
| 2 | Rotor | 3853838 | |
| 3 | Stator | 3854225 | |
| 3 | Stator | 3853837 | |
| 4 | Housing, rear | 3852646 | |
| 4 | Housing, rear | 3852646 | |
| 5 | Fan | 3852645 | |
| 5 | Fan | 3853756 | |
| 6 | Pulley | 3853755 | |
| 6 | Pulley | 3852644 | |
| 7 | Bearing, front & rear | 3852643 | |
| 7 | Bearing, front & rear | 3852643 | |
| 8 | Insulator, red | 3852624 | |
| 8 | Insulator, red | 3852624 | |
| 9 | Insulator, boot | 3852623 | |
| 9 | Insulator, boot | 3852623 | |
| 10 | Retainer, rear bearing | 3852642 | |
| 10 | Retainer, rear bearing | 3852642 | |
| 11 | Diode | 3852641 | |
| 11 | Diode | 3852641 | |
| 12 | Rectifier | 3853836 | |
| 12 | Rectifier | 3853836 | |
| 13 | Strap, b+ | 3852640 | |
| 13 | Strap, b+ | 3852640 | |
| 14 | Brush | 3853835 | |
| 14 | Brush | 3853835 | |
| 15 | Spacer, fan | 3852639 | |
| 15 | Spacer, fan | 3852639 | |
| 16 | Woodruff key, woodruff | 3852638 | |
| 16 | Woodruff key, woodruff | 3852638 | |
| 17 | Gasket | 3852637 | |
| 17 | Gasket | 3852637 | |
| 18 | Cardboard tube | 3853834 | |
| 18 | Cardboard tube | 3853834 | |
| 19 | Capacitor | 3852636 | |
| 19 | Capacitor | 3852636 | |
| 20 | Strap, ac tap | 3852635 | |
| 20 | Strap, ac tap | 3852635 | |
| 21 | Washer, pulley | 3852625 | |
| 21 | Washer, pulley | 3852625 | |
| 22 | Screw, capacitor | 3852736 | |
| 22 | Screw, capacitor | 3852736 | |
| 23 | Nut, pulley | 3852630 | |
| 23 | Nut, pulley | 3852630 | |
| 24 | Governor, voltage | 3853833 | |
| 24 | Governor, voltage | 3853757 | |
| 25 | Bolt, through | 3852634 | |
| 25 | Bolt, through | 3852634 | |
| 26 | Screw, front housing | 3852734 | |
| 26 | Screw, front housing | 3852734 | |
| 27 | Screw, regulator | 3852629 | |
| 27 | Screw, regulator | 3852629 | |
| 28 | Screw, alternator ground | 3852736 | |
| 28 | Screw, alternator ground | 3852736 | |
| 29 | Screw, diode field | 3852735 | |
| 29 | Screw, diode field | 3852735 | |
| 30 | Screw, diode field | 3852628 | |
| 30 | Screw, diode field | 3852628 | |
| 31 | Nut | 3852633 | |
| 31 | Nut | 3852633 | |
| 32 | Nut | 3852632 | |
| 32 | Nut | 3852632 | |
| 33 | Washer, insulator | 3852732 | |
| 33 | Washer, insulator | 3852732 | |
| 34 | Washer | 3852626 | |
| 34 | Washer | 3852626 | |
| 35 | Baffle | 3853881 | |
| 35 | Baffle | 3853881 | |
| 36 | Screw, terminal | 3852737 | |
| 36 | Screw, terminal | 3852737 | |
| 37 | Nut retainer, alternator brace to pump | 3853403 | |
| 37 | Nut retainer, alternator brace to pump | 3853403 | |
| 38 | Flange screw, alternator to bracket | 3853367 | |
| 38 | Flange screw, alternator to bracket | 3853367 | |
| 39 | Flange screw, bracket | 3853547 | |
| 39 | Flange screw, bracket | 3853547 | |
| 40 | Washer, screw alternator | 3852058 | |
| 40 | Washer, screw alternator | 3852058 | |
| 41 | Washer, ground | 3852069 | |
| 41 | Washer, ground | 3852069 | |
| 42 | Nut, alternator to bracket | 3852051 | |
| 42 | Nut, alternator to bracket | 3852051 | |
| 43 | Bracket, alternator | 3853883 | |
| 43 | Bracket, alternator | 3853883 | |
| 44 | Bushing, alternator | 3852740 | |
| 44 | Bushing, alternator | 3852740 | |
| 45 | Flange screw, brace to alternator | 3853396 | |
| 45 | Flange screw, brace to alternator | 3853396 | |
| 46 | Brace, alternator | 3852761 | |
| 46 | Brace, alternator | 3852761 | |
| 47 | Washer, brace to alternator | 3852054 | |
| 47 | Washer, brace to alternator | 3852054 | |
| 48 | Nut, alternator excite wire | 3852185 | |
| 48 | Nut, alternator excite wire | 3852185 | |
| 49 | Tab washer, alternator excite wire | 3852001 | |
| 49 | Tab washer, alternator excite wire | 3852001 |
