| # | Наименование | Код | |
| 1 | Thermostat housing | 3589553 | |
| 1 | Housing | 3850360 | |
| 1 | Thermostat housing | 3863086 | |
| 2 | Plug | 3850740 | |
| 2 | Plug | 3850740 | |
| 2 | Plug | 3850740 | |
| 3 | Thermostat | 3587597 | |
| 3 | Thermostat | 3587597 | |
| 3 | Thermostat | 3856961 | |
| 4 | O-ring | 983944 | |
| 4 | O-ring | 983944 | |
| 4 | O-ring | 3852071 | |
| 5 | Gasket | 3852111 | |
| 5 | Gasket | 3852111 | |
| 5 | Gasket | 3852111 | |
| 6 | Flange screw | 3853391 | |
| 6 | Flange screw | 3853388 | |
| 6 | Flange screw | 3853388 | |
| 7 | Washer | 3852162 | |
| 7 | Washer | 3852162 | |
| 7 | Washer | 980933 | |
| 8 | Bracket | 3852649 | |
| 8 | Bracket | 3852649 | |
| 8 | Bracket | 3852649 | |
| 9 | Flange screw | 3853401 | |
| 9 | Flange screw | 3853401 | |
| 9 | Flange screw | 3853401 | |
| 10 | Hose | 3860588 | |
| 10 | Hose | 3857843 | |
| 10 | Hose | 3860588 | |
| 11 | Hose | 3857843 | |
| 11 | Hose | 3862536 | |
| 11 | Hose | 3862536 | |
| 12 | Clamp | 982714 | |
| 12 | Hose clamp | 3863439 | |
| 12 | Hose clamp | 3853780 | |
| 13 | Clamp | 982714 | |
| 13 | Clamp | 982714 | |
| 13 | Hose | 3858237 | |
| 14 | Clamp | 982644 | |
| 14 | Hose | 3858237 | |
| 14 | Hose | 3858237 | |
| 15 | Hose clamp | 3863441 | |
| 15 | Hose clamp | 3852602 | |
| 15 | Hose | 3852288 | |
| 16 | Hose clamp | 3852098 | |
| 16 | Hose | 3860400 | |
| 16 | Hose | 3860400 | |
| 17 | Circulation pump | 3853850 | |
| 17 | Hose clamp | 3863438 | |
| 17 | Hose clamp | 3852098 | |
| 18 | Gasket | 3852477 | |
| 18 | Circulation pump | 3853850 | |
| 18 | Circulation pump | 3853850 | |
| 19 | Stud | 3856147 | |
| 19 | Gasket | 3852477 | |
| 19 | Gasket | 3852477 | |
| 20 | Bolt | 3856137 | |
| 20 | Stud | 3856147 | |
| 20 | Stud | 3856147 | |
| 21 | Bolt | 3856137 | |
| 21 | Stud | 3852507 | |
| 21 | Bolt | 3856137 | |
| 22 | Washer | 3852162 | |
| 22 | Stud | 3852507 | |
| 22 | Stud | 3852507 | |
| 23 | Washer | 980933 | |
| 23 | Washer | 3852162 | |
| 23 | Pulley | 3852220 | |
| 24 | Screw | 3853390 | |
| 24 | Pulley | 3852220 | |
| 24 | Pulley | 3852220 | |
| 25 | Cover | 3858532 | |
| 25 | Screw | 3853390 | |
| 25 | Screw | 3853390 | |
| 26 | Cover | 3858532 |
