| # | Наименование | Код | |
| 1 | Repair kit, 290 DP | 3855518 | |
| 1 | Carburetor | 3850712 | |
| 1 | Carburetor, 290 DP | 3854584 | |
| 1 | Float | 3853575 | |
| 2 | Kit | 3854106 | |
| 3 | Gasket | 3852758 | |
| 4 | Diaphragm, accelerator pump, carburetor | 3854257 | |
| 5 | Choke | 3854108 | |
| 6 | Stud, carburetor mounting | 3853074 | |
| 7 | Washer, electric choke lead | 3852191 | |
| 8 | Nut, stud, carburetor assy | 3852142 | |
| 9 | Stud, flame arrestor & cover to carburetor | 3853560 | |
| 10 | Cover, flame arrestor | 3850510 | |
| 11 | Washer | 3852007 | |
| 12 | Pad, cover, flame arrestor | 3850458 | |
| 13 | Nut, flame arrestor cover | 3852749 | |
| 14 | Cable, electric choke-ground | 3853845 | |
| 15 | Drain cock | 3854253 | |
| 16 | Terminal, ring, 0.312 | 3852037 | |
| 17 | Cover, terminal | 3854259 | |
| 18 | Screw, throttle lever to carburetor | 3850415 | |
| 19 | Screw, throttle lever | 3852154 | |
| 20 | Nut, screw, throttle lever to carburetor | 3853758 | |
| 21 | Lock nut, throttle lever to carburetor | 3854468 | |
| 22 | Washer, throttle cable to lever | 3852049 | |
| 23 | Split pin, throttle cable to lever | 3852052 | |
| 24 | Intermediate lever, carburetor | 3850217 | |
| 25 | Spacer, carburetor | 3853073 | |
| 26 | Nut, flame arrestor to carburetor | 3853561 | |
| 27 | Flame shield, carburetor | 3854026 | |
| 28 | Connector, hose to flame arrestor | 3852695 | |
| 29 | Hose, valve cover to flame arrester | 3852668 | |
| 30 | Adapter, throttle cable | 3850941 | |
| 31 | Washer | 3852193 | |
| 32 | Retainer | 3852019 | |
| 33 | Decal | 3854985 | |
| 34 | Decal | 3854980 | |
| |$0 | Bulletin P-23-1-1 | 0004028549 |
