Crankcase

Product image
1 1 2 2 3 3 4 4 5 5 6 6 7 7 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 14 14 14 14 14 14 15 15 15 15 15 15 15 15 16 16 17 17 17 17 17 17 17 17 17 17 18 18 19 19 20 20 21 21 22 22 22 22 22 22 22 22 23 23 23 23 23 23 23 23 24 24 24 24 24 24 24 24 25 25 25 25 25 25 25 25 26 26 26 27 27 27 27 28 28 28 28 29 29 29 29 30 30 30 30 31 31 32 32 32 32 32 32 32 32 32 32 32 32 32 32 33 33 34 34 35 35 36 36 37 37 38 38 39 39 40 40 41 41 42 42 42 42 43 43 44 44 44 44 45 45 46 46 47 47 48 48 49 49 50 50 51 51 52 52 52 52 53 53 54 54 54 55 55 55 56 56 57 57 58 58 58 59 59 60 60 61 61 61 61 62 62 63 63 63 63 63 63 63 63 64 64 65 65 66 66 67 67 68 68 69 69 70 70 71 72 73 74 |$0 |$0 |$32 |$32 |$36 |$36 |$40 |$40 |$44 |$44
# Наименование Код
1 Longblock 3856684
1 Longblock 3856683
2 Guide sleeve, cylinder head to block 3853007
2 Guide sleeve, cylinder head to block 3853007
3 Cap plug, core hole 3852650
3 Cap plug, core hole 3852650
4 Cap plug 3853008
4 Cap plug, oil passage 3853008
5 Plug, oil gallery 3853108
5 Plug, oil gallery 3853108
6 Cap plug, oil passage 3853008
6 Cap plug, oil passage 3853008
7 Expansion plug, rear, cam, standard 3852766
7 Cap plug, rear cam, 0.060 in. os 3853009
7 Cap plug, rear cam, 0.060 in. os 3853009
7 Expansion plug, rear, cam, standard 3852766
8 Locating pin, adapter hsg to block 3853076
8 Locating pin, adapter hsg to block 3853076
9 Bolt, main bearing cap 3853065
9 Bolt, main bearing cap 3853065
10 Stud, main bearing cap 3853066
10 Stud, main bearing cap 3853066
11 Nut, main bearing cap 3853026
11 Nut, main bearing cap 3853026
12 Cap plug, rear hole in block 3853010
12 Cap plug, rear hole in block 3853010
13 Crankshaft 3852792
13 Crankshaft, 851200 model 3852792
14 Piston ring kit, 0.020 in. os 3853844
14 Piston ring kit, standard (pkg. of 2 3853900
14 Piston ring kit, 0.040 in. os 3853885
14 Piston ring kit, 0.040 in. os 3853885
14 Piston ring kit, 0.030 in. os 3853879
14 Piston ring kit, 0.030 in. os 3853879
14 Piston ring kit, standard (pkg. of 2) 3853900
14 Piston ring kit, 0.020 in. os 3853844
15 Piston, standard 3857020
15 Piston, 0.040 in. os 3857023
15 Piston, standard 3857020
15 Piston, 0.020 in. os 3857021
15 Piston, 0.020 in. os 3857021
15 Piston, 0.030 in. os 3857022
15 Piston, 0.040 in. os 3857023
15 Piston, 0.030 in. os 3857022
16 Piston pin, piston, standard 3852773
16 Piston pin, piston, standard 3852773
17 Bearing, connecting rod, 0.020 in. U.S. 3853042
17 Bearing, connecting rod, standard 3852775
17 Bearing, connecting rod, 0.040 in. U.S. 3853044
17 Bearing, connecting rod, 0.040 in. U.S. 3853044
17 Bearing, connecting rod, 0.010 in. U.S. 3853041
17 Bearing, connecting rod, 0.010 in. U.S. 3853041
17 Bearing, 0.020 in. U.S. 3853042
17 Bearing, connecting rod, 0.030 in. U.S. 3853043
17 Bearing, connecting rod, 0.030 in. U.S. 3853043
17 Bearing, connecting rod, standard 3852775
18 Connecting rod 3853901
18 Connecting rod 3853901
19 Nut, connecting rod 3852777
19 Nut, connecting rod 3852777
20 Bolt, connecting rod 3852776
20 Bolt, connecting rod 3852776
21 Camshaft 3852778
21 Camshaft 3853770
22 Bearing, upper, standard 3852797
22 Bearing, main, upper, 0.030 in. U.S. 3853049
22 Bearing, main, upper, 0.030 in. U.S. 3853049
22 Bearing, main, upper, 0.020 in. U.S. 3853048
22 Bearing, main, upper; 0.020 in. U.S. 3853048
22 Bearing, main, upper, 0.010 in. U.S. 3853047
22 Bearing, main, upper, 0.010 in. U.S. 3853047
22 Bearing, upper, standard 3852797
23 Bearing, main, lower, 0.010 in. U.S. 3853052
23 Bearing, main, lower, 0.010 in. U.S. 3853052
23 Bearing, lower, standard 3852798
23 Bearing, lower, standard 3852798
23 Bearing, main, lower, 0.030 in. U.S. 3853054
23 Bearing, main, lower, 0.020 in. U.S. 3853053
23 Bearing, main, lower, 0.030 in. U.S. 3853054
23 Bearing, main, lower, 0.020 in. U.S. 3853053
24 Bearing, main, center, lower, 0.010 in. U.S. 3853062
24 Bearing, main, center, lower, 0.030 in. U.S. 3853064
24 Bearing, main, center, lower, 0.030 in. U.S. 3853064
24 Bearing, main, center, lower, 0.020 in. U.S. 3853063
24 Bearing, main, center, lower, 0.020 in. U.S. 3853063
24 Bearing, main, center, lower, 0.010 in. U.S. 3853062
24 Bearing, center, lower, standard 3852800
24 Bearing, center, lower, standard 3852800
25 Bearing, main, center, upper, 0.010 in. U.S. 3853057
25 Bearing, main, center, upper, 0.020 in. U.S. 3853058
25 Bearing, main, center, upper 0.030 in. U.S. 3853059
25 Bearing, main, center, upper 0.030 in. U.S. 3853059
25 Bearing, main, center, upper, 0.010 in. U.S. 3853057
25 Bearing, center, upper, standard 3852799
25 Bearing, center, upper, standard 3852799
25 Bearing, main, center, upper, 0.020 in. U.S. 3853058
26 Bearing, center, 0.015 in. U.S. 3853019
26 Bearing, camshaft, center 3852781
26 Bearing, camshaft, center 3852781
27 Bearing, rear, 0.015 in. U.S. 3853020
27 Bearing, camshaft, rear 3852782
27 Bearing, rear, 0.015 in. U.S. 3853020
27 Bearing, camshaft, rear 3852782
28 Bearing, front intermediate, 0.015 in. U.S. 3853022
28 Bearing, front intermediate, 0.015 in. U.S. 3853022
28 Bearing, camshaft 3852783
28 Bearing, camshaft 3852783
29 Bearing, rear intermediate, 0.015 in. U.S. 3853023
29 Bearing, rear intermed., 0.015 in. U.S. 3853023
29 Bearing, camshaft, rear intermediate 3852784
29 Bearing, camshaft, rear intermediate 3852784
30 Bearing, front, 0.015 in. U.S. 3853018
30 Bearing, camshaft, front 3852780
30 Bearing, front, 0.015 in. U.S. 3853018
30 Bearing, camshaft, front 3852780
31 Bolt, camshaft sprocket 3852791
31 Bolt, camshaft sprocket 3852791
32 Sprocket, crankshaft 0004028300
32 Sprocket, crankshaft 3852794
32 Sprocket, crankshaft 3852794
32 Sprocket, camshaft 3852785
32 Sprocket, camshaft 3852785
32 Sprocket, crankshaft 0004028178
32 Chain, timing 0004028177
32 Sprocket, camshaft 0004028179
32 Sprocket, camshaft 0004028301
32 Chain, Set 3856737
32 Chain 3853903
32 Chain 3853903
32 Chain 0004028302
32 Chain, Set 3856737
33 Woodruff key, sprocket 3852795
33 Woodruff key, sprocket 3852795
34 Washer, camshaft sprocket 3852790
34 Washer, camshaft sprocket 3852790
35 Washer 3853075
35 Washer 3853075
36 Locating pin, camshaft sprocket 3852786
36 Locating pin, camshaft sprocket 3852786
37 Seal, crankshaft, rear 3852805
37 Seal, crankshaft, rear 3852805
38 Vibration damper, crankshaft 3855196
38 Vibration damper, crankshaft 3855196
39 Bolt, crankshaft damper 3853021
39 Bolt, crankshaft damper 3853021
40 Eccentric, fuel pump, outer 3852673
40 Eccentric, fuel pump, outer 3852673
41 Eccentric, fuel pump, inner 3852789
41 Eccentric, fuel pump, inner 3852789
42 Plate, camshaft thrust, 0.002 in. os 3853024
42 Plate, camshaft thrust, standard 3852787
42 Timing gear casing 3853893
42 Plate, camshaft thrust, 0.004 in. os 3853025
43 Bolt, thrust plate 3852788
43 Bolt, thrust plate 3852788
44 Timing gear casing, cylinder front 3853893
44 Plate, 0.004 in. os, camshaft thrust 3853025
44 Plate, 0.002 in. os, camshaft thrust 3853024
44 Plate, camshaft thrust, standard 3852787
45 Turn signal, timing 3852768
45 Turn signal, timing 3852768
46 Insert, oil filter 3853035
46 Insert, dil filter 3853035
47 Flywheel 3853953
47 Flywheel 3853953
48 Gear ring, flywheel 3852804
48 Gear ring, flywheel 3852804
49 Seal, front cover 3853827
49 Seal, front cover 3853827
50 Clamp, distributor 3853078
50 Clamp, distributor 3853078
51 Screw, clamp, distributor 3853077
51 Screw, clamp, distributor 3853077
52 Lock nut, dampener to flywheel 3854497
52 Washer, dampener to flywheel 3854496
52 Washer, dampener to flywheel 3854496
52 Lock nut, dampener to flywheel 3854497
53 Nut 3853273
53 Nut 3853273
54 Rubber coupling, flywheel 3853862
54 Rubber coupling, flywheel 3853862
54 Oscillation damper, flywheel 3850520
55 Stud, flywheel & coupler to crankshaft 3853274
55 Stud, flywheel & coupler to crankshaft 3853274
55 Stud, shoulder, dampener to flywheel 3854495
56 Cover, flywheel 3853003
56 Stud, shoulder, dampener to flywheel 3854495
57 Oil filter 835779
57 Oil filter 835779
58 Screw, flywheel cover to hsg 3852421
58 Screw, flywheel cover to hsg 3852421
58 Cover 3853003
59 V-belt pulley, crankshaft 3855088
59 Cover, engine 3853003
60 V-belt pulley, crankshaft 3855088
60 V-belt pulley 3855088
61 Oil pressure sensor, oil pressure 3853800
61 Oil pressure sensor, dil pressure 3853800
61 Oil pressure sensor, 0il psi, dual station 834921
61 Oil pressure sensor, oil psi, dual station 834921
62 Gasket, front cover 3852767
62 Gasket, front cover 3852767
63 Bolt, front cover, 2-1/4 in 3853013
63 Bolt, front cover, 2-1/4 in 3853013
63 Bolt, front cover, 2-1/2 in 3853014
63 Bolt, front cover, 2 in 3853011
63 Bolt, front cover, 2-1/2 in 3853014
63 Bolt, front cover,1-314 in 3853012
63 Bolt, front cover,1-314 in 3853012
63 Bolt, front cover, 2 in 3853011
64 Oscillation damper 3850520
64 Oscillation damper 3850520
65 Flange screw 3853557
65 Flange screw, pulley to crankshaft 3853557
66 Nipple, oil pressure sending unit 3852712
66 Fitting, oil pressure switch & sender 3853640
67 Fitting, oil pressure sending unit 3852711
67 Breaker 3854181
68 Cardboard tube, fuel pump opening 3854284
68 Bushing, pilot, crankshaft 3850412
69 Gasket, fuel pump opening 3852600
69 Screw, flywheel to crankshaft 3855532
70 Drain cock 3854494
70 Flange screw, fuel pump cover 3853266
71 Elbow, street, oil pressure switch 3852503
72 Bushing, pilot, crankshaft 3850412
73 Screw, flywheel to crankshaft 3855532
74 Drain cock 3854494
|$0 Bulletin P-21-0-7 0004028235
|$0 Bulletin P-21-0-7 0004028112
|$32 Bulletin P-21-6-1 0004028268
|$32 Bulletin P-21-6-1 0004028145
|$36 Bulletin P-21-6-1 0004028273
|$36 Bulletin P-21-6-1 0004028150
|$40 Bulletin P-21-6-1 0004028155
|$40 Bulletin P-21-6-1 0004028278
|$44 Bulletin P-21-6-1 0004028160
|$44 Bulletin P-21-6-1 0004028283
