Upper Intake Manifold

Product image
1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 34 34 35 35 35 36 36 37 37 38 38 39 39 40 40 41 41 42 42 43 43 44 44 45 45 46 46 46 47 47 48 48 49 49 50 50 51 51 51 51 52 52 53 53 54 54 55 55 56 56 57 57 58 58 59 59 60 60 61 61 62 62 63 63 63 64 64 65 65 66 66 66 66 67 67 68 68 69 69 70 70 71 71 72 72 73 73 74 74 75 75 76 76 77 77 78 78 79
# Наименование Код
1 Valve, PCV 3852820
1 Valve 3852820
2 Hose clamp, hose, upper intake manifold to filter 3852529
2 Protective cap, map sensor screw 3853537
3 Elbow, hose, pcv valve 3852480
3 Elbow, hose, pcv valve 3852480
4 Nut, stud, throttle body 3852142
4 Nut, stud, throttle body 3852142
5 Flange screw, .TFI module to mounting bracket 3852080
5 Flange screw, .TFI module to mounting bracket 3852080
6 Cable tie, eng cbi lead, idle air by connector 3852158
6 Cable tie, eng cbl lead, idle air by connector 3852158
7 Hose clamp, hose, upper intake manifold to filter 3852529
7 Hose clamp, filter hose to intake 3852529
8 Screw, E-coil & bracket to TFI 3852168
8 Screw, E-coil & bracket to TFI 3852168
9 Hose clamp, hose, filter 3852196
9 Clamp, hose, filter to intake manifold 3852170
10 Clamp, pres regulator hose to intake manifold 3852171
10 Clamp, hose, filter to intake manifold 3852170
11 Hose clamp, hose, map sensor 3852196
11 Clamp, hose, map sensor 3852170
12 Hose clamp, hose, reservoir to pulse limiter 3852529
12 Hose clamp, hose, reservoir to pulse limiter 3852529
13 Throttle body 3854277
13 Shutter housing, Fi 3850768
13 Throttle body, Fsi 3855163
14 Nut, screw, throttle lever to throttle body 3852077
14 Nut, screw, throttle lever to throttle body 3852077
15 Screw, lever & pin assy to throttle body 3852066
15 Screw, lever & pin assy to throttle body 3852066
16 Screw, throttle lever to throttle body 3852212
16 Screw, throttle lever to throttle body 3852212
17 Adapter, air bypass solenoid 3853612
17 Adapter, air bypass solenoid 3853612
18 Gasket, throttle air bypass solenoid 3853613
18 Gasket, throttle air bypass solenoid 3853613
19 Sensor 3850988
19 Sensor 3850988
20 Screw, air bypass solenoid 3853614
20 Screw, air bypass solenoid 3853614
21 Nut, shoulder, throttle lever 3853627
21 Nut, shoulder, throttle lever 3853627
22 Bracket, throttle body 3850353
22 Bracket, throttle body 3850353
23 Screw, throttle sensor 3850986
23 Screw, throttle sensor 3850986
24 Gasket, adapter to solenoid 3853613
24 Gasket, adapter to solenoid 3853613
25 Screw, throttle air bypass solenoid 3853614
25 Screw, throttle air bypass solenoid 3853614
26 Valve, throttle air bypass 3850987
26 Valve, throttle air bypass 3850987
27 Clip, connector 3853734
27 Clip, connector 3853734
28 Filter, adapter, throttle air bypass solenoid 3853748
28 Filter, adapter, throttle air bypass solenoid 3853748
29 Grommet, pcv valve 3853767
29 Grommet, pcv valve 3853767
30 Nut, throttle cable 3853729
30 Nut, throttle cable 3853729
31 Filter, crankcase vent 3853768
31 Filter, crankcase vent 3853768
32 Cardboard tube, screw, hex idle air adjustment 3853772
32 Cardboard tube, screw, hex idle air adjustment 3853772
33 Retainer, throttle cable 3852019
33 Washer, throttle bracket 3852162
34 Bracket, styling cover to TFI/E-coil bracket 3853775
34 Adapter, throttle cable 3850941
35 Hose, map sensor to filter 3854903
35 Hose, map sensor to filter 3852203
35 Hose 3852377
36 Hose, filter to intake manifold 3852376
36 Hose, filter to upper intake manifold 3853641
37 Screw, E-coil bracket to TFI bracket 3852212
37 Screw, E-coil bracket to TFI bracket 3852212
38 Filter, map sensor, vacuum line 3852224
38 Filter, map sensor, vacuum line 3852224
39 Impulse limiter, upper intake manifold 3852225
39 Impulse limiter, upper intake manifold 3852225
40 Bushing, pulse limiter to intake manifold 3852465
40 Screw, upper to lower intake manifold, center 3853760
41 Cable tie, reservoir vent hose 3852486
41 Screw, upper to lower intake manifold 3853635
42 Hose clamp, hose, pcv valve 3852529
42 Screw, upper to lower intake manifold 3853638
43 Hose, valve cover to arrestor 3853723
43 Hose, valve cover to arrestor 3853723
44 Bracket, TFI module & E-coil 3853763
44 Bracket, TFI module & E-coil 3853763
45 Hose, reservoir to pulse limiter 3853582
45 Hose, reservoir to pulse limiter 3853582
46 Grommet, flame arrestor, to throttle body 3850922
46 Grommet, flame arrestor, to throttle body 3853594
46 Grommet, flame arrestor, to throttle body 3853594
47 Clamp, flame arrestor to throttle body 3853595
47 Clamp, flame arrestor to throttle body 3853595
48 Hose, pressure regulator 3853619
48 Hose, pressure regulator 3853765
49 Bracket, ignition coil to TFI bracket 3853625
49 Bracket, ignition coil to TFI bracket 3853625
50 Gasket, TFI/E-coil mounting bracket 3853761
50 Gasket, TFI/E-coil mounting bracket 3853629
51 Gasket, TFI/E-coil mounting bracket 3853630
51 Decal 3854990
51 Decal 3854989
51 Decal 3851032
52 Inlet pipe, upper intake 3850777
52 Manifold 3854276
53 Stud, throttle body to upper intake manifold 3852176
53 Stud, throttle body to upper intake manifold 3852176
54 Screw, map sensor to elec components brkt 3852208
54 Protective cap, map sensor screw 3853537
55 Fitting, pressure regulator hose 3853639
55 Fitting, pressure regulator hose 3853639
56 Bracket, styling cover to rear intake manifold 3853762
56 Bracket, flame arrestor cover, rear 3853652
57 Hose, upper intake manifold to pcv valve 3854904
57 Hose, upper intake manifold to pcv valve 3854904
58 Flange screw, bracket, flame arrestor cover 3853661
58 Flange screw, bracket, flame arrestor cover 3853661
59 Control unit 3854139
59 Control unit 3854139
60 Level sensor 3854272
60 Level sensor 3854272
61 Screw 3854273
61 Screw 3854273
62 Control unit 3854274
62 Control unit 3854274
63 Flame shield, throttle body, Fi 3854144
63 Flame shield, throttle body, FSi 3850915
63 Flame shield, throttle body 3854144
64 Coil 3854161
64 Coil 3854161
65 Screw, intake manifold, upper to lower 3853638
65 Retainer, throttle cable 3852019
66 Cover, flame arrestor & throttle body 3853571
66 Decal 3851033
66 Decal 3854988
66 Cover, flame arrestor & throttle body 3853571
67 Screw, flame arrestor clamp 3853722
67 Screw, flame arrestor clamp 3853722
68 Anchor, throttle cable 3850266
68 Anchor, throttle cable 3850266
69 Bracket, throttle, anchor to intake manifold 3850225
69 Bracket, throttle anchor to intake manifold 3850226
70 Intake gasket, upper to lower intake manifold 3853636
70 Intake gasket, upper to lower intake manifold 3853637
71 Screw, stylint cover bracket 3852207
71 Screw, intake manifold, upperto lower 3853635
72 Screw, styling cover to intake manifold 3853764
72 Flange screw, flame arrestor cover to engine 3853662
73 Nut, anchor, throttle cable to bracket 3852118
73 Nut, anchor, throttle cable to bracket 3852118
74 Screw, cable anchor 3852048
74 Screw, cable anchor 3852048
75 Sensor, manifold air pressure 3854160
75 Sensor, manifold air pressure 3854160
76 Screw, map sensor 3853764
76 Cardboard tube, Nipple 3853745
77 Adapter 3850941
77 Hose clamp, cap to upper intake manifold 3852529
78 Nut, throttle cable adapter 3853729
78 Elbow, map sensor 3852480
79 Nut 3853729
