| # | Наименование | Код | |
| 1 | Expansion tank | 861105 | |
| 1 | Thermostat housing | 3589553 | |
| 2 | Pressure cap | 1674083 | |
| 2 | Thermostat | 3587597 | |
| 3 | Decal | 3858552 | |
| 3 | O-ring | 983944 | |
| 4 | Bracket | 3861849 | |
| 4 | Gasket | 3852111 | |
| 5 | Flange screw | 968842 | |
| 5 | Hose | 3860955 | |
| 6 | Hose clamp | 3860413 | |
| 6 | Clamp | 982643 | |
| 6 | Bracket | 3852649 | |
| 7 | Thermostat housing | 3860555 | |
| 7 | Flange screw | 945444 | |
| 8 | Elbow nipple | 3860585 | |
| 8 | Elbow | 3853597 | |
| 9 | Hose clamp | 3860413 | |
| 9 | Flange screw | 3860163 | |
| 10 | Flange screw | 969189 | |
| 10 | Hose | 3862550 | |
| 11 | Gasket | 3852111 | |
| 11 | Hose | 3817847 | |
| 12 | Thermostat kit | 3831426 | |
| 12 | Hose | 3862536 | |
| 13 | Sealing ring | 416033 | |
| 13 | Hose clamp | 3863439 | |
| 14 | Clamp | 982715 | |
| 14 | Thermostat housing | 3851384 | |
| 15 | Flange screw | 945444 | |
| 15 | Hose clamp | 3812303 | |
| 16 | Lifting eye | 3861919 | |
| 16 | Hose | 3817817 | |
| 17 | Hose | 3862852 | |
| 17 | Hose clamp | 3863441 | |
| 18 | Clamp | 982716 | |
| 18 | Hose | 3862523 | |
| 19 | Clamp | 982715 | |
| 19 | Hose clamp | 3863438 | |
| 20 | Hose nipple | 983744 | |
| 20 | Circulation pump | 3853850 | |
| 21 | Circulation pump | 3853850 | |
| 21 | Gasket | 3852477 | |
| 22 | Stud | 3856147 | |
| 22 | Gasket | 3852477 | |
| 23 | Stud | 3856147 | |
| 23 | Nut retainer | 3853403 | |
| 24 | Nut retainer | 3853403 | |
| 24 | Bolt | 3856137 | |
| 25 | Bolt | 3856137 | |
| 25 | Bolt | 3856136 | |
| 26 | Pulley | 3860083 | |
| 26 | Bolt | 3856136 | |
| 27 | Flange screw | 3863054 | |
| 27 | Pulley | 3860083 | |
| 28 | Flange screw | 3863054 | |
| 28 | Fuel pump | 0003160659 | |
| 29 | Hose | 3861741 | |
| 30 | Hose clamp | 3812304 | |
| |$0 | Bulletin p-26-1-7 | 0003160600 | |
| |$0 | Bulletin P-18-4-4 | 0003160599 |
