Купить Бензиновые двигатели 5.0GLPEFS 5.0GiPEFS 5.7GSPEFS 5.7GSIPEFS Fuel System Carburetor для лодочных моторов Volvo Penta в Москве

1 1 2 2 2 3 4 5 6 7 8 9 10 11 12 13 14 15 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 |$4

#	Наименование	Код
1	Float	3853575
1	Carburetor kit	3858335
2	Repair kit	3854020
2	Repair kit	3854347
2	Kit, rebuild	21533400
3	Gasket, carburetor to adapter	3853280
4	Gasket, adapter to manifold	3850405
5	Diaphragm, accelerator pump, carburetor	3854257
6	Choke	3853992
7	Cardboard tube, nipple, carburetor	3852082
8	Cable tie, Nipple	3852158
9	Washer, electric choke lead	3852191
10	Nut, stud, carburetor to adapter	3852142
11	Stud, flame arrestor & cover	3853560
12	Decal	3854980
13	Pad, cover, flame arrestor	3850458
14	Flame shield	3856862
15	Decal	3857569
15	Decal	3855282
16	Hose, flame arrestor to valve cover	3852668
17	Nut, flame arrestor cover	3852749
18	Cable, electric choke	3853845
19	Terminal, 0.250	3854258
20	Terminal, 0.312	3852037
21	Cover, terminal	3854259
22	Screw, throttle lever to carburetor	3850415
23	Screw, throttle lever to carburetor	3852154
24	Nut, throttle lever	3853758
25	Nut, screw, throttle lever to carburetor	3853758
26	Washer, throttle cable to lever	3852049
27	Split pin, cable to throttle lever	3852052
28	Intermediate lever, carburetor	3850217
29	Adapter, carburetor to intake manifold	3857997
30	Nut, flame arrestor	3853561
31	Screw, adapter, carburetor to intake manifold	3852864
32	Stud, carburetor to adapter	3853373
33	Washer, nut, flame arrestor cover	3852007
34	Adapter, throttle cable	3850941
35	Washer, pin, throttle cable to lever	3852193
36	Cover, flame arrestor	3850510
37	Retainer, bracket, throttle cable	3852019
\|$4	Bulletin P-23-1-3	0004046877
