| # | Наименование | Код | |
| 1 | Thermostat housing | 3589553 | |
| 1 | Expansion tank | 861105 | |
| 2 | Plug | 3850740 | |
| 2 | Pressure cap | 1674083 | |
| 3 | Thermostat | 3587597 | |
| 3 | Decal | 3858552 | |
| 4 | O-ring | 983944 | |
| 4 | Bracket | 3842583 | |
| 5 | Gasket | 3852111 | |
| 5 | Hose | 3860955 | |
| 6 | Hose clamp | 3860413 | |
| 6 | Screw | 3853388 | |
| 6 | Clamp | 982643 | |
| 7 | Thermostat housing | 3860555 | |
| 7 | Washer | 980933 | |
| 8 | Elbow nipple | 3860585 | |
| 8 | Bracket | 3852649 | |
| 9 | Screw | 3860163 | |
| 9 | Screw | 3853401 | |
| 10 | Hose | 3860588 | |
| 10 | Screw | 3853391 | |
| 11 | Hose | 3862536 | |
| 11 | Washer | 3852162 | |
| 12 | Gasket | 3852111 | |
| 12 | Hose clamp | 3863439 | |
| 13 | Clamp | 982715 | |
| 13 | Thermostat kit | 3831426 | |
| 14 | Clamp | 982714 | |
| 14 | Sealing ring | 416033 | |
| 15 | Hose | 3817817 | |
| 15 | Thermostat housing | 3851384 | |
| 16 | Hose clamp | 3863441 | |
| 16 | Screw | 3853401 | |
| 17 | Washer | 3852162 | |
| 17 | Hose | 3860400 | |
| 18 | Hose clamp | 3863438 | |
| 18 | Lifting eye | 3861919 | |
| 19 | Hose | 3842131 | |
| 19 | Circulation pump | 3853850 | |
| 20 | Clamp | 982716 | |
| 20 | Gasket | 3852477 | |
| 21 | Stud | 3856147 | |
| 21 | Hose clamp | 3863439 | |
| 22 | Hose nipple | 983744 | |
| 22 | Bolt | 3856137 | |
| 23 | Circulation pump | 3853850 | |
| 23 | Pulley | 3860083 | |
| 24 | Screw | 3863054 | |
| 24 | Gasket | 3852477 | |
| 25 | Stud | 3856147 | |
| 26 | Bolt | 3856137 | |
| 27 | Pulley | 3860083 | |
| 28 | Screw | 3853390 | |
| 29 | Hose | 3841899 | |
| 30 | Hose clamp | 3812304 | |
| |$0 | Bulletin p-26-1-7 | 0003704443 | |
| |$0 | Bulletin P-18-4-4 | 0003704442 |
