Engine Harness

1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 34 34 35 35 36 36 37 37 38 38 39 39 40 40 41 41 42 42 43 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 |$43

#	Наименование	Код
1	Wiring harness	3860037
1	Wiring harness	3860036
2	Cable seal, knock sensor	3857189
2	Terminal, engine ground	3852527
3	Terminal, oil pressure switch	3852084
3	Terminal casing, knock sensor	3853480
4	Cardboard tube, oil pressure switch	3853320
4	Terminal	3852527
5	Terminal, oil pressure switch	3852233
5	Terminal	3852084
6	Cardboard tube	3853320
6	Terminal, ac tap	3852233
7	Terminal, alternator excite	3852235
7	Terminal	3852229
8	Terminal, alternator ground	3852245
8	Connector	3853565
9	Cable, ignition coil	3854244
9	Terminal, alternator ind light	3852233
10	Terminal, alternator excite	3852235
10	Rubber cap	3852130
11	Terminal, alternator output	3852038
11	Terminal, alternator output	3852038
12	Terminal, aternator sense	3852233
12	Terminal, alternator sense	3852235
13	Terminal, water temp switch	3852084
13	Bracket, fuel pump ignition relay	3852210
14	Terminal	3852246
14	Cardboard tube, water temp switch	3853320
15	Terminal	3852247
15	Terminal, starter solenoid	3852233
16	Terminal, high pressure fuel pump	3853679
16	Terminal, starter solenoid, starter terminal	3852235
17	Connector housing	3855021
17	Terminal, starter solenoid	3852527
18	Terminal, starter solenoid	3852527
18	Trunk	3853681
19	Terminal, low pressure fuel pump	3853679
19	Nut, circuit breaker	3852064
20	Terminal, starter solenoid, starter terminal	3852235
20	Tab washer, circuit breaker	3852001
21	Automatic fuse	3854238
21	Terminal, alternator output	3852527
21	Automatic fuse	3854163
21	Automatic fuse	3854164
22	Terminal, starter solenoid	3852527
22	Terminal, circuit breaker to splice	3852245
23	Relay, starter relay	3854192
23	Terminal	3852245
24	Terminal, starter relay	3852254
24	Automatic fuse, 50 amp	3854164
25	Terminal, ground electical bracket	3852227
25	Relay, starter relay	3854192
26	Relay, starter relay	3854192
26	Terminal, starter relay	3852227
27	Terminal, starter relay	3852254
27	Terminal	3852254
28	Terminal, choke	3852084
28	Connector housing	0004046238
29	Cable seal	3857189
29	Pulley, choke	3852220
30	Terminal, water temp transmitter	3852233
30	Terminal	3852233
31	Bracket	3852210
31	Cable tie	3852158
32	Relay	3850403
32	Terminal	3852229
33	Terminal	3852246
33	Connector, 2 pin	3853565
34	Terminal, fuel pump	3852247
34	Connector housing	0004046244
35	Cable seal	3857189
35	Terminal, fuel pump	3853679
36	Connector, fuel pump	0004046202
36	Cable terminal, injector	3850671
37	Connector	3857142
37	Terminal, fuel pump	0004046203
38	Cable, ignition coil dist terminal	3854244
38	Terminal	3852233
39	Connector, trim sender	3853565
39	Connector housing, distributor	0004046249
40	Fuse, 40 amp	979686
40	Terminal, trim sender	3852229
41	Fuse, 40 amp	979686
41	Fuse, 15 amp	966329
42	Fuse, 7.5 amp	969197
42	Fuse, 20 amp	968547
43	Fuse holder	3860455
43	Fuse holder	3860455
44	Engine control modul, electronic control module	3860098
45	Sensor	3854905
46	Switch	3850397
47	Sensor	3850396
48	Module	3854672
49	Bracket, knock module	3850272
50	Flange screw, knock module bracket	3852115
51	Bracket	3851990
52	Flange screw, bracket to adapter	3852115
53	Screw, ECM to bracket	3855578
54	Flange screw, knock module to bracket	3852115
55	Hose, map sensor	3850688
56	Flange screw, map sensor to bracket	3852115
57	Hose clamp, hose, map sensor	3852172
\|$43	Bulletin P-28-4-9	0004046255
