Crankcase and Oil Pan

1 2 2 3 3 4 5 6 7 8 8 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 30 31 32 33 34 34 35 36 37 38 39 40 41 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 58 59 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 78 79 80 81 82 83 |$0 |$0 |$0 |$16 |$89

#	Наименование	Код
1	Longblock	3858440
2	Piston, standard	3855742
2	Piston, 0.50 mm os	3855743
3	Piston ring, 0.50 mm os	3855741
3	Piston ring, standard	3855740
4	Bearing, camshaft	3856778
5	Pin, rear oil seal housing	3856140
6	Core plug, expansion	3852100
7	Core plug, rear camshaft bearing	3853209
8	Bearing, main, standard	3856772
8	Bearing, main 0.020 in os	3856774
8	Bearing, main 0.010 in os	3856773
9	Locating pin, cylinder head	3853114
10	Pin, timing cover	3855972
11	Pin, flywheel housing	3856001
12	Bolt, bearing cap	3853214
13	Bearing, rod, standard	3854955
14	Connecting rod	3854173
15	Nut, connecting rod	3853148
16	Bolt, connecting rod	3853179
17	Housing, rear oil seal	3857716
18	Stud, rear oil seal	3857718
19	Seal, rear oil	3856926
20	Gasket, rear oil seal housing	3852656
21	Bolt, rear oil seal	3853203
22	Nut, rear oil seal housing	3853206
23	Stud, rear oil seal housing	3853205
24	Crankshaft	3855733
25	Pin, flywheel	3855969
26	Bolt, rear oil seal	3853204
27	Chain	3852685
28	Sprocket, camshaft	3854319
29	Retainer, camshaft	3854329
30	Stud, timing cover	3855738
30	Vibration damper	3855734
31	Plug, water drain	3850802
32	Rubber coupling	3858437
33	Timing gear casing	3855735
34	Screw, timing cover	3855736
34	Screw, timing cover	3855737
35	Grommet, timing cover	3855739
36	Woodruff key, crankshaft	3853648
37	Bolt, lifter guide retainer	3855817
38	Stud, coupler to engine	3853274
39	Adapter, oil sending unit	3855776
40	Bolt, camshaft retainer	3854323
41	Pressure sensor, oil pressure dual station	872064
41	Oil pressure sensor, oil pressure	3857532
42	Sprocket, crankshaft	3852690
43	Bolt, camshaft sprocket	3854330
44	Elbow, oil sending unit	3852503
45	Guide, valve lifter	3855825
46	Nut, stud, coupler to flywheel	3853273
47	Flywheel	3854325
48	Gear, flywheel	3853207
49	Camshaft	3854328
50	Pin, camshaft sprocket	3857717
51	Bolt, balancer shaft gear	3854320
52	Cardboard tube, balancer shaft	3854217
53	Shaft, balancer	3857715
54	Core plug, rear balancer shaft bearing	3853209
55	Bearing, balancer shaft rear	3854315
56	Screw, balancer shaft retainer	3853172
57	Gear, balancer shaft	3854314
58	Hexagon screw, damper	949518
58	Screw, damper	949519
59	Tab washer, damper	3852046
59	Washer, damper	3858177
60	Washer, damper	3852110
61	Fitting, oil pressure switch	3850660
62	Sensor, oil pressure	3852215
63	Bearing, balancer shaft, forward	3850519
64	Gasket kit, oil pan	3855801
65	Shaft, distributor to oil pump	3853198
66	Retainer, distributor to oil pump	3853199
67	Bolt, oil pump to block	3853234
68	Oil pump	3856125
69	Oil strainer, oil pump	3857714
70	Tube	3855723
71	Gauge	3850473
72	O-ring, oil gage tube to fitting	3852033
73	Washer, retainer, oil pan drain	3852007
74	Retainer, oil pan drain	3855721
75	O-ring, retainer, oil pan drain	3853674
76	Fitting, oil pan drain	3855722
77	Washer, fitting to oil pan	3851981
78	Sump	3858697
78	Sump	3855800
79	Fitting, oil filter	3853174
80	Oil filter	841750
81	Stud, oil pan, front	3857718
82	Nut, oil pan	3856930
83	Bolt, oil pan	3855802
\|$0	Bulletin P-21-0-14	0004041462
\|$0	Bulletin P-21-0-28	0004041463
\|$0	Bulletin P-21-0-12	0004041461
\|$16	Bulletin P-21-6-2	0004041480
\|$89	Bulletin P-21-7-1	0004041554
