Fuel System

Product image
1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 13 13 14 14 15 15 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 30 30 31 31 32 32 33 33 34 34 35 35 36 36 37 37 38 38 39 39 40 40 41 41 42 42 43 43 44 44 45 45 46 46 47 47 48 48 49 49 50 50 51 51 52 52 53 53 54 54 55 55 56 56 57 57 58 58 59 59 60 60 61 61 61 61 62 62 63 63 64 64 65 65 66 66 67 67 68 68 69 69 70 70 71 71 71 71 72 72 73 73 74 74 75 75 76 76 77 77 78 78 79 79 80 80 81 81 82 82 |$64 |$64 |$64 |$64
# Наименование Код
1 Fuel pump 3854280
1 Fuel pump 3854280
2 O-ring, fuel line to tbi, 0.375 3850424
2 O-ring, fuel line to tbi, 0.375 3850424
3 Grommet, fuel pump to cover 3852481
3 Grommet, fuel pump to cover 3852481
4 Tube, pump to TBI 3854775
4 Tube, pump to TBI 3854775
5 O-ring, fitting 3850820
5 O-ring, fitting 3850820
6 Fitting, valve, high pressure fuel pump 3854924
6 Fitting, valve, high pressure fuel pump 3854924
7 Bracket, fuel pump grommet 3853573
7 Bracket, fuel pump grommet 3853573
8 Tube, tBI to reservoir 3854773
8 Tube, tBI to reservoir 3854773
9 O-ring, fuel line to tbi; 0.312 3850423
9 O-ring, fuel line to tbi; 0.312 3850423
10 Cable tie, engine cable to fuel pump assy 3852158
10 Cable tie, engine cable to fuel pump assy 3852158
11 Adapter, fuel line 3852017
11 Adapter, fuel line 3852017
12 Fitting, tBI to reservoir 3852462
12 Fitting, tBI to reservoir 3852462
13 Clamp, hose, reservoir to pulse limiter 3852170
13 Hose clamp, hose, reservoir to pulse limiter 3852529
13 Clamp, hose, reservoir to pulse limiter 3852170
13 Hose clamp, hose, reservoir to pulse limiter 3852529
14 Impulse limiter, reservoir to TBI adapter 3852225
14 Impulse limiter, reservoir to TBI adapter 3852225
15 Elbow, pulse limiter to TBI adapter 3852503
15 Elbow, pulse limiter to TBI adapter 3852503
16 Hose, vapor separator to pulse limiter 3854870
16 Hose, vapor separator to pulse limiter 3854870
17 Elbow, vent, reservoir to intake 3853597
17 Elbow, vent, reservoir to intake 3853597
18 Protective cap, pressure valve 3853616
18 Protective cap, pressure valve 3853616
19 Valve, reservoir assy 3854152
19 Valve, reservoir assy 3854152
20 Screw, cover to reservoir 3853606
20 Screw, cover to reservoir 3853606
21 Cardboard tube, reservoir 3854405
21 Cardboard tube, reservoir 3854405
22 Gasket, float needle seat 3853577
22 Gasket, float needle seat 3853577
23 Spring seat, float needle 3853576
23 Spring seat, float needle 3853576
24 Needle, float 3853578
24 Needle, float 3853578
25 Retainer, float pin 3852034
25 Retainer, float pin 3852034
26 O-ring, retainer, fuel pump 3853642
26 O-ring, retainer, fuel pump 3853642
27 Retainer, fuel pump to cover 3853572
27 Retainer, fuel pump to cover 3853572
28 Clip, needle to float 3853579
28 Clip, needle to float 3853579
29 Float, reservoir assy 3853575
29 Float, reservoir assy 3853575
30 Pin 3853622
30 Pin 3853622
31 Gasket, cover 3853574
31 Gasket, cover 3853574
32 Reservoir, vapor separator 3854149
32 Reservoir, vapor separator 3854149
33 Stud, oil cooler clamp to reservoir 3852093
33 Stud, oil cooler clamp to reservoir 3852093
34 Hose, vapor separator to oil cooler 3853580
34 Hose, vapor separator to oil cooler 3853580
35 Screw, reservoir to bracket 3853558
35 Screw, reservoir to bracket 3853558
36 Nut, reservoir to bracket 3850657
36 Nut, reservoir to bracket 3850657
37 Screw, reservoir to bracket 3853558
37 Screw, reservoir to bracket 3853558
38 Fitting, reservoir, port nipple 3856449
38 Fitting, reservoir, port nipple 3856449
39 Bracket, reservoir to flywheel hsg 3850271
39 Bracket, reservoir to flywheel hsg 3850271
40 Elbow, reservoir to thermostat hsg 3852480
40 Elbow, reservoir to thermostat hsg 3852480
41 Hose clamp, hose to reservoir, antisiphon valve 3852196
41 Hose clamp, hose to reservoir, antisiphon valve 3852196
42 Plug, reservoir drain 3852167
42 Plug, reservoir drain 3852167
43 Rubber hose, reservoir to thermostat hsg 943367
43 Rubber hose, reservoir to thermostat hsg 943367
44 Hose clamp, hose, antisiphon valve 3854925
44 Hose clamp, hose, antisiphon valve 3854925
45 Nipple, hoses, thermostat hsg to reservoir 3850666
45 Nipple, hoses, thermostat hsg to reservoir 3850666
46 Hose, antisiphon valve to thermostat hsg 3850633
46 Hose, antisiphon valve to thermostat hsg 3850633
47 Flange screw, lift bracket, fuel pump & relay assy 3853326
47 Flange screw, lift bracket, fuel pump & relay assy 3853326
48 Bracket, fuel pump, support bracket & filter 3853310
48 Bracket, fuel pump, support bracket & filter 3853310
49 Kit, fuel reservoir 3850374
49 Kit, fuel reservoir 3850374
50 Hexagon screw, circuit breaker to bracket 3853620
50 Hexagon screw, circuit breaker to bracket 3853620
51 Bracket, fuel pump & relay mounting 3853544
51 Bracket, fuel pump & relay mounting 3853544
52 Bracket, relay 3852210
52 Bracket, relay 3852210
53 Screw, relay & cable assy 3852208
53 Screw, relay & cable assy 3852208
54 Relay, fuel pump 3850403
54 Relay, fuel pump 3850403
55 Grommet, fuel pump 3852481
55 Grommet, fuel pump 3852481
56 Automatic fuse, 20A, fuel pump 3854163
56 Automatic fuse, 20A, fuel pump 3854163
57 Attaching clamp, fuel line to bracket, intake 3852231
57 Attaching clamp, fuel line to bracket, intake 3852231
58 Flange screw, fuel line clamp to bracket 3852115
58 Flange screw, fuel line clamp to bracket 3852115
59 Tab washer, circuit breaker 3852001
59 Tab washer, circuit breaker 3852001
60 Nut, circuit breaker terminals 3852064
60 Nut, circuit breaker terminals 3852064
61 Sensor, water temperature 3852029
61 Sensor, water temperature 3852029
61 Temperature sensor, water temperature, dual station 872068
61 Temperature sensor, water temperature, dual station 872068
62 Kit 3850861
62 Kit 3850861
63 Fuel filter 3851218
63 Fuel filter 3851218
64 Flange screw, fuel pump, support bracket, fuel filter 3853266
64 Flange screw, fuel pump, support bracket, fuel filter 3853266
65 Elbow, inlet, fuel filter cover 3852013
65 Elbow, inlet, fuel filter cover 3852013
66 Fitting, fuel pump to fuel filter cover 3853493
66 Fitting, fuel pump to fuel filter cover 3853493
67 O-ring, fitting 3850819
67 O-ring, fitting 3850819
68 Fuel pump, electric, low pressure 3854620
68 Fuel pump, electric, low pressure 3854620
69 Fitting, fuel pump to fuel line 3853545
69 Fitting, fuel pump to fuel line 3853545
70 Gasket, adapter to intake manifold 3850405
70 Gasket, adapter to intake manifold 3850405
71 Adapter, TBI to intake manifold 3850270
71 Adapter, TBI to intake manifold 3850270
71 Plug, adapter, TBI to intake manifold 3850740
71 Plug, adapter, TBI to intake manifold 3850740
72 Gasket, TBI to adapter 3850355
72 Gasket, TBI to adapter 3850355
73 Throttle body 3850354
73 Throttle body 3850354
74 Stud, TBI to adapter 3852160
74 Stud, TBI to adapter 3852160
75 Nut, stud, TBI to adapter 3852142
75 Nut, stud, TBI to adapter 3852142
76 Bracket, throttle cable 3850297
76 Bracket, throttle cable 3850297
77 Flange screw, lever & pin assy to throttle body 3853428
77 Flange screw, lever & pin assy to throttle body 3853428
78 Nut retainer, shoulder screw, throttle lever to TBI 3852420
78 Nut retainer, shoulder screw, throttle lever to TBI 3852420
79 Shoulder screw, lever & pin assy to throttle body 3850411
79 Shoulder screw, lever & pin assy to throttle body 3850411
80 Fuel pipe, pump to reservoir 3854774
80 Fuel pipe, pump to reservoir 3854774
81 Bracket, fuel iine & hose to intake manifold 3854906
81 Bracket, fuel iine & hose to intake manifold 3854906
82 Cardboard tube, nipple, throttle body 3856766
82 Cardboard tube, nipple, throttle body 3856766
|$64 Bulletin P-23-3-4 0004026935
|$64 Bulletin p-18-8-1 0004026848
|$64 Bulletin p-18-8-1 0004026936
|$64 Bulletin P-23-3-4 0004026847
