Carburetor

Product image
1 1 1 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 7 7 7 8 8 8 9 9 9 10 10 10 11 11 11 12 12 12 13 13 13 14 14 14 15 15 15 16 16 16 17 17 17 18 18 18 18 19 19 19 20 20 20 21 21 21 22 22 22 23 23 23 24 24 24 25 25 25 26 26 26 27 27 27 28 28 28 29 29 29 30 30 30 31 31 31 32 32 32 33 33 33 34 34 34 35 35 35 36 36 36 37 37 37 38 38 38 39 39 |$0 |$0
# Наименование Код
1 Float 3853575
1 Carburetor 3854346
1 Float 3853575
1 Float 3853575
1 Carburetor 3850288
1 Carburetor 3854346
2 Repair kit 3854020
2 Kit 3854341
2 Repair kit 3854020
3 Gasket, carburetor to adapter 3853497
3 Gasket, carburetor to adapter 3853280
3 Gasket, carburetor to adapter 3853280
4 Gasket, adapter to manifold 3853279
4 Gasket, adapter to manifold 3853279
4 Gasket, adapter to manifold 3852437
5 Diaphragm, accelerator pump 3854257
5 Diaphragm, accelerator pump 3854257
5 Diaphragm, accelerator pump 3854257
6 Choke 3853992
6 Choke 3853992
6 Diaphragm 3853991
7 Cardboard tube, Nipple 3852082
7 Cardboard tube, Nipple 3852082
7 Choke 3853992
8 Cable tie, Nipple 3852158
8 Cardboard tube, Nipple 3852082
8 Cable tie, Nipple 3852158
9 Washer, choke ground 3852191
9 Washer, choke ground 3852191
9 Cable tie, Nipple 3852158
10 Washer, choke ground 3852191
10 Nut, stud, carburetor mounting 3852142
10 Nut, stud, carburetor mounting 3852142
11 Stud, flame arrestor 3853560
11 Nut, stud, carburetor mounting 3852142
11 Stud, flame arrestor 3853560
12 Cover, flame arrestor 3850510
12 Stud, flame arrestor 3853560
12 Cover, flame arrestor 3850510
13 Pad, flame arrestor cover 3850458
13 Flame shield 3854026
13 Pad, flame arrestor cover 3850458
14 Flame shield 3854026
14 Flame shield 3854026
14 Connector, crankcase venthose 3852695
15 Hose, crankcase vent,9' (229 mm) 3852435
15 Connector, c'case vent hose 3852695
15 Connector, c'case vent hose 3852695
16 Hose, 9 in. (229 mm) 3852435
16 Cover, flame arrestor 3850510
16 Hose, 9 in. (229 mm) 3852435
17 Nut, cover 3852749
17 Pad, flame arrestor cover 3850458
17 Nut, cover 3852749
18 Cable, choke ground 3853845
18 Cable, choke ground 3853845
18 Washer, cover 3852007
18 Nut, cover 3852749
19 Drain cock 3854253
19 Cable, choke ground 3853845
19 Drain cock 3854253
20 Terminal 3854258
20 Terminal, ring 3852037
20 Terminal, ring 3852037
21 Terminal, ring 3852037
21 Cover, terminal 3854259
21 Cover, terminal 3854259
22 Screw, throttle lever 3850415
22 Screw, throttle lever 3850415
22 Cover, terminal 3854259
23 Screw, throttle lever 3850415
23 Screw, throttle lever 3852154
23 Screw, throttle lever 3852154
24 Nut, throttle lever 3853758
24 Screw, throttle lever 3852154
24 Nut, throttle lever 3853758
25 Nut retainer, throttle lever 3852420
25 Nut retainer, throttle lever 3852420
25 Decal 3854980
26 Washer, throttle cable to lever 3852049
26 Nut, throttle lever 3853758
26 Washer, throttle cable to lever 3852049
27 Split pin, throttle cable to lever 3852052
27 Nut retainer, throttle lever 3852420
27 Split pin, throttle cable to lever 3852052
28 Intermediate lever 3850232
28 Washer, throttle cable to lever 3852049
28 Intermediate lever 3850232
29 Adapter, carb. to intake manifold 3855903
29 Intermediate lever 3850217
29 Adapter, carb. to intake manifold 3853278
30 Nut, flame arrestor 3853561
30 Nut, flame arrestor 3853561
30 Adapter, carb. to intake 3853277
31 Nut, flame arrestor 3853561
31 Screw, adapter to intake manifold 3852864
31 Screw, adapter to intake manifold 3852864
32 Screw, adapter to intake manifold manifold 3852864
32 Stud, carburetor to adapter 3853373
32 Stud, carburetor to adapter 3853373
33 Stud, carburetor to adapter 3853276
33 Washer, cover 3852007
33 Washer, cover 3852007
34 Decal 3854983
34 Adapter, throttle cable 3850941
34 Adapter, throttle cable 3850941
35 Washer, throttle cable adapter 3852193
35 Washer, throttle cable adapter 3852193
35 Adapter, throttle cable 3850941
36 Split pin, throttle cable 3852052
36 Split pin, throttle cable 3852052
36 Washer, throttle cable adapter 3852193
37 Retainer, throttle cable 3852019
37 Retainer, throttle cable 3852019
37 Split pin, throttle cable 3852052
38 Retainer, throttle cable 3852019
38 Decal 3854980
38 Decal 3854980
39 Decal 3854982
39 Decal 3854982
|$0 Bulletin P-23-1-1 0004027001
|$0 Bulletin P-23-1-1 0004026959
