Crankcase

1 2 2 3 3 4 5 5 5 6 7 8 9 10 11 11 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 37 38 39 40 40 40 41 42 43 44 45 46 47 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 |$0 |$0 |$0 |$0 |$21

#	Наименование	Код
1	Longblock	3856682
2	Piston, 0.50 mm os	3855743
2	Piston, standard	3855742
3	Piston ring, standard	3855740
3	Piston ring, 0.50 mm os	3855741
4	Cap plug, oil gallery	3853208
5	Bearing	3856778
5	Bearing, camshaft, #2 & #3	3853212
5	Bearing, camshaft, #1 & #4	3853210
6	Nut, oil pan	3853206
7	Pin, rear oil seal housing	3856140
8	Core plug, engine block	3852100
9	Core plug, camshaft	3853209
10	Plug	3852471
11	Bearing, 0.020 in. U.S.	3856774
11	Bearing, 0.010 in. U.S.	3856773
11	Bearing, standard	3856772
12	Locating pin, cylinder head	3853114
13	Pin, front cover	3855972
14	Pin, trans line-up	3856001
15	Bolt, bearing cap	3853214
16	Bearing, standard	3854955
17	Connecting rod	3854173
18	Nut, connecting rod	3853148
19	Bolt, connecting rod	3853179
20	Housing, rear oil seal	3857716
21	Stud, oil pan, rear	3857718
22	Seal, rear crankshaft	3852657
23	Gasket, rear oil seal	3852656
24	Bolt, seal retainer	3853204
25	Nut, seal retainer	3853206
26	Stud, seal retainer	3853205
27	Crankshaft	3855733
28	Pin, flywheel dowel	3853200
29	Bolt, seal retainer	3853203
30	Chain, camshaft timing	3852685
31	Pin	3855969
32	Sprocket, camshaft	3854319
33	Retainer, camshaft sprocket	3854329
34	Timing gear casing	3855735
35	Stud, timing cover	3855738
36	Screw, timing cover	3855737
37	Plug, water drain, engine	3850802
37	Drain cock, engine	3854494
38	Clutch, flywheel	3853917
39	Vibration damper	3855734
40	Stud, timing cover	3855738
40	Screw, timing cover	3855737
40	Screw, timing cover	3855736
41	Stud, flywheel & coupler to crankshaft	3853274
42	Woodruff key, crankshaft	3853648
43	Bolt, valve lifter guide	3855817
44	Grommet, timing cover	3855739
45	Adapter	3855776
46	Bolt, camshaft retainer	3854323
47	Oil pressure sensor, oil pressure	3853800
47	Pressure sensor, oil pressure, dual station	872064
48	Sprocket, crankshaft	3852690
49	Bolt, camshaft sprocket	3854330
50	Elbow, oil pressure sender to adapter	3852503
51	Guide	3855824
52	Nut, flywheel & coupler to crankshaft	3853273
53	Flywheel	3854325
54	Gear, flywheel	3855970
55	Camshaft	3854328
56	Pin, camshaft	3857717
57	Bolt, balancer gear	3854320
58	Retainer, balancer shaft	3854317
59	Bearing	3854315
60	Shaft	3857715
61	Core plug, balancer hole	3853209
62	Screw, balancer shaft retainer	3853172
63	Gear, balancer shaft	3854314
64	Stud, camshaft sprocket	3854313
65	Nut, camshaft sprocket stud	3853168
66	Oscillation damper, flywheel, 290 DP	855656
67	Screw, torsional damper	835482
68	Spring washer	942336
69	Screw	835439
70	Spring washer	941909
71	Washer, screw, damper to flywheel	940097
72	Fitting, adapter, oil pressure switch	3850660
73	Sensor, oil pressure	3852215
74	Bearing, balancer shaft, forward	3850519
75	Fitting, drain, knock sensor	3850490
\|$0	Bulletin P-21-0-15	0004026331
\|$0	Bulletin P-21-0-28	0004026333
\|$0	Bulletin P-21-0-16	0004026332
\|$0	Bulletin P-21-0-12	0004026330
\|$21	Bulletin P-21-6-2	0004026355
