#	Наименование	Код
1	Steering pump, P/S pump to engine	3850491
2	Bracket	3852512
3	Washer, pis pump bracket	3852162
4	Washer, stud, water pump & steering pump	3852162
5	V-belt, P/S pump	3852464
6	Hose, cylinder to oil cooler, P/S	3854056
7	O-ring, pressure hose to steering pump	3852497
8	Hose, oil cooler to steering pumo, return	3852839
9	Hose, gimbal to cooler	3852281
9	Hose	3850283
10	Pulley	3853804
11	Hose	3853918
12	Nut, oil cooler & bracket assy	3852079
13	Spacer, oil cooler, P/S	3853236
14	Screw, oil cooler & bracket assy	3852126
15	Fitting, steering hoses	3853315
16	Cable tie	3852158
17	Oil cooler, P/S	3852840
18	Flange screw, P/S cooler clamp to flywheel hsg	3853326
18	Nut, P/S cooler clamp to reservoir	3852177
19	Clamp, engine oil cooler, P/S	3852218
20	Screw, steering pump bracket	3853405
21	Stud, water/steering pump bracket to engine	3852507
22	Flange screw, plug lead retainer bracket to cyl head	3853557
23	Clamp, hoses to cylinder head	3852837
24	Stud, oil cooler clamp to reservoir	3852093
25	Nut retainer, stud, P/S pump bracket	3853403
26	Nut retainer, stud, P/S pump bracket	3853403
27	Flange screw, lift bracket/clamp, P/S hoses to head	3853557
28	Attaching clamp, steering pump hoses to front mount	3852490
29	Hose clamp, hose, oil cooler, bypass pipe	3852602
30	Hose clamp, hose, P/S pump to oil cooler	3852196
31	Hose clamp, hose, water to gimbal hsg	3853786
32	Hose, cooler to thermostat	3852281
33	Stud, P/S pump bracket to engine	3853402
34	Washer, stud, P/S pump bracket	3852054
35	Washer, oil cooler clamp to reservoir	3852058
