Flywheel Housing and Mounts

Product image
1 1 2 2 3 3 4 4 5 5 6 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 14 15 15 16 16 16 17 17 18 18 19 19 20 20 21 21 22 22 23 23 24 24 25 25 26 26 27 27 28 28 29 29 29 30 30 30 31
# Наименование Код
1 Flywheel housing 3851017
1 Housing 3853457
2 Primary shaft 873013
2 Cover 3854604
3 Gasket 3852834
3 Sealing ring, primary shaft 958859
4 Hose, flywheel hsg 3852832
4 Ball bearing, primary shaft 3851019
5 Snap ring, primary shaft 914533
5 Screw, flywheel cover 3852421
6 Flange screw, flywheel hsg to engine 3853392
6 Flange screw, reservoir and flywheel hsg to engine 3853547
6 Snap ring, primary shaft 914462
7 Sealing ring, primary shaft 958860
7 Tab washer, ground stud, flywheel hsg 3852002
8 Washer, ground stud, flywheel hsg 3852058
8 Cover plate, flywheel housing 854939
9 Hexagon screw, flywheel cover to housing 947224
9 Rubber cushion, engine front 3853805
10 Flange screw 3853547
10 Hexagon screw, rear mount to transom plate 959968
11 Rubber cushion, transom plate 3853972
11 Flange screw, flywheel housing to engine 3850753
12 Bushing, primary shaft to crankshaft 3860697
12 Washer, rear mount to transom plate 3852155
13 Hexagon screw, rear mount 3850930
13 Stud, flywheel housing to engine 3850571
14 Washer 3852058
14 Tab washer 3852002
14 Lock nut, rear mount 3850929
15 Washer, rear mount to flywheel hsg 3852540
15 Nut 3852065
16 Clamping ring kit, flywheel housing 854316
16 Ring 0003973043
16 Square nut, rear mount 3852539
17 Washer, rear mount 3852622
17 Striker plate, clamp ring 806624
18 Washer, rear mount 3852542
18 Hexagon screw 191844
19 Stud, flywheel housing to engine 3852483
19 Rubber ring, clamp ring 813967
20 Nut, terminal to ground stud, flywheel hsg 3852065
20 Washer 3852070
21 Washer, spacer, reservoir bracket 3852058
21 Washer, ground stud, flywheel hsg 3852070
22 Bracket, front, port and starboard 3852760
22 Rubber cushion, engine front 3853805
23 Flange screw, front mount bracket to engine 3853326
23 Bracket, front, port and starboard 3852760
24 Flange screw, front mount bracket to engine 3853326
24 Bolt, front mount 3852566
25 Washer, bolt, front mount, engine 3852428
25 Bolt, front mount 3852566
26 Washer, front mount 3852433
26 Tab washer, bolt, front mount, engine 3852090
27 Washer, front mount 3852433
27 Nut, bolt, mount bracket 3852021
28 Tab washer, front mount 3852090
28 Nut, bolt, mount bracket 3852021
29 Attaching clamp 3852092
29 Washer, front mount 3852428
29 Clamp 3852434
30 Clamp, starter leads to stbd bracket 3852146
30 Attaching clamp 3852490
30 Clamp, starter leads to stbd bracket 3852146
31 Clamp 3853312
