| # | Наименование | Код | |
| 1 | Alternator | 872018 | |
| 2 | rotor | 000149713 | |
| 3 | Stator | 859421 | |
| 6 | housing | 000149720 | |
| 7 | Ball bearing | 860432 | |
| 8 | housing | 000149722 | |
| 11 | Diode bridge | 872383 | |
| 12 | Bearing race | 840629 | |
| 13 | Ball bearing | 864351 | |
| 14 | Protecting casing | 840631 | |
| 15 | 000149727 | ||
| 15 | Regulator kit | 872367 | |
| 17 | Brush retainer | 840632 | |
| 18 | Hexagon nut | 955779 | |
| 18 | Flange nut | 945407 | |
| 18 | Flange nut | 965483 | |
| 19 | Spring washer | 941904 | |
| 5A | Fan kit | 860281 | |
| 5B | fan | 000149716 | |
| 5C | Spacer | 862897 | |
| 5D | Spacer | 860284 | |
| 5E | Washer | 860283 |
