| # | Наименование | Код | |
| 1 | Carburetor | 841047 | |
| 2 | housing | 0002511267 | |
| 3 | cover | 0002511268 | |
| 4 | throttle housing | 0002511269 | |
| 5 | gasket | 0002511270 | |
| 6 | idle adjusting screw | 0002511271 | |
| 7 | spring | 0002511272 | |
| 8 | Screw | 841631 | |
| 9 | Vakuum switch | 834990 | |
| 10 | Screw | 841627 | |
| 11 | Hose | 948958 | |
| 12 | housing | 0002511277 | |
| 13 | Choke | 841612 | |
| 14 | Retainer | 826154 | |
| 15 | Screw | 826155 | |
| 16 | Spring | 835577 | |
| 17 | Filter | 835576 | |
| 18 | Gasket | 834991 | |
| 19 | Gasket | 834994 | |
| 20 | Pipe connection | 834992 | |
| 21 | seal | 0002511286 | |
| 22 | floot needle assy | 0002511287 | |
| 23 | Piston | 841622 | |
| 24 | Spring | 841624 | |
| 25 | main jet | 0002511290 | |
| 26 | retainer and ball | 0002511291 | |
| 27 | Float | 841620 | |
| 28 | Float spindle | 841621 | |
| 29 | gasket | 0002511294 | |
| 30 | Metering needle | 841616 | |
| 31 | pump, assy | 0002511296 | |
| 32 | spring | 0002511297 | |
| 33 | Screw | 841615 | |
| 34 | Screw | 841631 | |
| 35 | Screw | 841613 | |
| 36 | pin | 0002511301 | |
| 37 | Screw, choke lever | 841626 | |
| 38 | gasket | 0002511303 | |
| 39 | grommet | 0002511304 | |
| 40 | Baffle | 841850 | |
| 41 | Gasket | 856033 | |
| 41 | Repair kit | 841236 |
